Hioki PW3198 Power Quality Analyzer
The Hioki PW3198 is a 3-Phase, 4-Wire Power Quality Analyzer. This model is compliant with IEC61000-4-30 Class A Standards and comes with harmonic and inter-harmonic analysis and Dynamic 1300V range capabilities. This model is an ideal solution for recording and monitoring power supply anomalies, as well as assessing problems across power supplies, such as flickering, voltage drops, harmonics, and other electrical issues. This Power Quality Analyzer`s broad voltage range enables the user to measure harmonic components up to 80 kHz. With this model, the user can complete measurements on different line types, such as single-phase 2 & 3-wire or three-phase 3 & 4 wire.
The Hioki PW3198 Power Quality Analyzer can be utilized for voltage measurements as high as 600.00 V rms, as well as for transient measurements to 6.0000 kV peak. As far as its current measurement capability is concerned, this model can be used for a large range of current encompassing 500.00 mA to 5.0000 kA AC. The Hioki PW3198 is a precise instrument, since it can measure voltage with ±0.1% basic accuracy. This model offers a comprehensive range of measurement items. In addition to general and routine applications, this model can also be used for the measurements of EC Flicker, Δ V10 Flicker, and K Factor (multiplication factor). The Hioki PW3198 features multiple communication interfaces, which are LAN and RS-232C. It also offers an HTTP server function. In addition, SD/SDHC memory card and USB 2.0 interfaces are provided for comfortable handling of storage-related functions.
| Model | PW3198 |
|---|---|
| Manufacturer | Hioki |
| Type | Power Quality Analyzer |
| Voltage Range | 600.00 V rms |
| Current Range | 500.00 mA to 5.0000 kA AC |
| Power Range | 300.00 W to 3.0000 MW |
| Display | 6.5-inch TFT color LCD |
| PW3198 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Request a Quote Today for Pricing |
