Fluke 1630 Earth Ground Clamp Meter
The 1630 is an efficiently performing earth ground clamp meter created by Fluke. The 1630 clamp meter offers advanced capabilities and simplified operational techniques. This model enables the user to quickly carry out loop testing for earth ground. The user can also measure the leakage currents that are non-intrusive without breaking the continuity of the circuit. The 1630 earth ground clamp meter implements the novel technique for this purpose. The instrument weighs around 750 grams.
The Fluke 1630 earth ground clamp meter offers a jaw opening to 35 mm or 1.38 inches, which permits the user to conduct testing for ground conductors and equipotential bus bars. This model can measure a wide range of ground leakage current from 0.2 mA to 1000 mA and an AC current from 0.2 to 30 amperes. The 1630 earth ground clamp meter additionally has an automatic self-calibration feature. This feature enables the user to receive accurate measurements for critical applications.
The Fluke 1630 earth ground clamp meter comes with a 999 digital LC display. It comes with a built-in feature for overload protection up to 200 amperes. This model also includes an overload indicator “OL” on display, which allows the user to swiftly identify the overload state. The instrument offers the measuring time of 0.5 seconds, a measuring frequency of 3.333 kHz, power consumption of 40 mA, and battery life for continuous operation of more than eight hours.
The Fluke 1630 Earth Ground Clamp Meter has a user manual available on the apexwaves.com website if you would further details about this product and its specifications and features.
| Model | Fluke 1630 |
|---|---|
| Manufacturer | Fluke |
| Type | Earth Ground Clamp Meter |
| Battery Life | ≥ 8 hours (continuous operation) |
| AC Current Measurement Range | 0.2 A to 30 A |
| Measuring Time | 0.5 sec |
| Overload Protection | 200 A |
| 1630 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
