Meters > Fluke > Fluke Meter
Fluke 189
Fluke 189 True RMS Multimeter with 0 to 1000 V DC voltage
Actual item may vary if no part number is provided on quote request.
✔ 2 Year Warranty Included
✔ Free Domestic Ground Shipping
✔ NIST Calibration Available
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Carol Zimme**** Verified Buyer
" Very responsive and helpful, competitive pricing. Good source! "
July 2025
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Fluke 189 True RMS Digital Multimeter
The Fluke 189 True RMS Multimeter has integrated holsters, swift readings, prolonged ranges, a high bandwidth, and extreme preciseness. This True RMS Digital Multimeter comes equipped with various beneficial features, such as a backlight, a dual display, a PC interface, and true-rms AC/AC + DC measurements. Furthermore, the readings memory on this model can hold as many as 100 readings. The logging function also permits the user to measure difficult to spot irregular issues. These features ensure the Fluke 189 is ideal for tough applications.
The Fluke 189 has the following specifications: a bandwidth voltage/current of 100 kHz, a quick min-max recording of 250 µsec, dimensions of 203 mm x 100 mm x 50 mm, a weight of 0.545 kg, and a battery life of approximately 72 hours. The Fluke 189 True RMS Multimeter has a CAT III 1000V / CAT IV 600 V protection rating, which means it will keep the meter and the user safe. This Multimeter is created for challenging conditions and can withstand environments that regular meters cannot.
On the Fluke 189 True RMS Digital Multimeter, the majority of measurement functions can be chosen through the rotary switch. Functions associated with frequency, such as pulse width, duty cycle, and Hz, can be chosen when the rotary switch is in the amps or volts setting. When any dc volts function is chosen, the Fluke 189 can show both ac and dc parts of a signal independently or together as an ac + dc rms value.
| Model | Fluke 189 |
|---|---|
| Manufacturer | Fluke |
| Type | True RMS Digital Multimeter |
| DC Voltage | 0 to 1000 V |
| AC Voltage (true rms) | 2.5 mV to 1000 V – 100 kHz bandwidth |
| Capacitance | 0.001 nF to 50 mF |
| Frequency | 0.5 Hz to 1000 kHz |
| Fluke 189 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
