Newport 2835-C Multi-Function Optical Meter
Newport 2835-C is a very versatile multi-functional optical device for accurately measuring the signal of a photodetector in an industrial automation environment and in a laboratory setting. This unit can be utilized as a primary control module for a wide variety of detectors from Newport’s line; this includes low-power semiconductor photodiodes, high-power thermopile detectors and energy-sensitive pyroelectric detectors. Calibration is facilitated through proprietary calibration modules that are specifically calibrated to each detector type. Each calibration module stores calibration information specific to the detector being measured and allows for accurate measurement while significantly reducing the amount of time required to set up the system and configure the unit for the detector that has been connected.
The Newport 2835-C has several capabilities when it comes to measuring DC current and peak-to-peak AC current and voltage. These measurements are then converted to direct measurements of the optical power or energy. Complex calculations of additional measurement units such as watts, Joules and dBm are also possible using this device. Other key features of this device include a 5.5-digit high-resolution vacuum fluorescent display, a fast update rate of 10 Hz, and trigger capabilities that allow for either input and/or output connections on BNC connectors. When utilizing this device within an automated system, there are two options for computer interface, GPIB (General Purpose Interface Bus) and RS-232, allowing for remote control of the device and logging of up to 1000 measurements per channel. Additionally, an analog output is available, providing a real-time voltage representation of the input signal for external monitoring and recording purposes.
The Newport 2835-C is a valuable resource for users that require a highly sensitive and flexible means of measuring the optical signal. Laser power and energy measurement, photodetector characterization, and automated test systems for optical devices are common uses for this device. In addition to its ability to measure across seven decades of gain, programmable operation and detector-specific calibration make the Newport 2835-C a vital component of many research and development and quality assurance processes that require the reliable and repeatable acquisition of optical data.
| Model | Newport 2835-C |
|---|---|
| Part Type | Optical Meter |
| Display | 5.5-digit VFD |
| Display Rate | 10 Hz |
| Detector Support | Semiconductor, Thermopile, Pyroelectric |
| Measurement Types | DC, Peak-to-Peak, Pulse/Energy |
| A/D Resolution | 20,000 counts |
| Gain Range | Up to 7 decades |
| Interfaces | RS-232, GPIB, BNC Analog, Trigger I/O |
| Input Power | 100–240 VAC, 50/60 Hz |
