ADLINK PXI-2204 Multi-Function DAQ Card
The part number PXI-2204 is a 64-channel multi-function DAQ (data acquisition) card that is designed for PXI automation platforms. The module offers 64 analog input channels that are single-ended with 16-bit resolution These channels can also be grouped together as 32 differential channels. It has a maximum sampling rate of 3 MS/s for accurate signal digitization in industrial test applications. The PXI-2204 DAQ Card offers multiple programmable input ranges from 0.05 volts to 10 volts in unipolar or bipolar configurations. This range flexibility enables the card to measure both low-level and high-level sensor outputs with precision. The DC input coupling ensures consistent signal response and minimal noise during continuous acquisition. Auto-calibration maintains stable performance and reduces drift across extended operating periods in harsh environments.
The ADLINK PXI-2204 DAQ module integrates two 12-bit multiplying analog output channels by supporting static and dynamic waveform generation. These outputs can generate programmable test stimuli or analog reference signals for closed-loop control systems. Each channel supports a driving capacity of 5 mA and maintains stability up to 1500 pico-farads. The PXI-2204 features 24 channel TTL digital input and output for precise control and monitoring. Its digital channel operates at standard logic levels and supports synchronous operation with analog signals. Two 16-bit general purpose counter/timer channels handle frequency measurement and event counting tasks. This integration allows the card to perform coordinated operations within a single compact module.
The available trigger sources include software control and external digital or analog trigger inputs. Trigger modes such as post-trigger, delay-trigger and repeated trigger provide flexibility for different test sequences. The PXI-2204 DAQ card supports both analog and digital triggering for precise timing control during data acquisition. The onboard FIFO buffer of 1Ksa per channel ensures uninterrupted data streaming. Its fata transfer options include programmed I/O and scatter-gather DMA for efficient bus utilization. This minimizes host CPU overhead and allows constant high-speed data throughput under continuous load. The ADLINK PXI-2204 uses Driver and SDK support which is available for Windows and Linux operating systems. The module includes a gain error of ±0.06% for the full-scale range (FSR). Its modular architecture provides precise synchronization with other measurement modules across the test platform. The module carries a lightweight configuration of only 5 lbs (2.26 kg) for easy handling in space-limited setups.
| Model | PXI-2204 |
|---|---|
| Manufacturer | ADLINK |
| Part Type | 64-Channel Multi-Function DAQ Card |
| Number of Channels | 64 |
| Driving Capacity | 5 mA |
| Resolution | 16-bit |
| Sampling Rate | 3 MS/s |
| FIFO Buffer Size | 1 Ksa |
| Weight | 5 lbs (2.26 kg) |
| Bipolar Input Voltage Ranges | ±0.05 V to ±10 V |
