ADLINK Technology Inc. PCI-8124 Encoder Card
The PCI-8124 card comes equipped with four differential quadrature encoder counter input channels, which is reasonable for cutting edge line check application which necessitate high line rates. The PCI-8124 has inward FIFO to understand the fast position look at and trigger pulse output. ADLINK suggests the user can utilize the PCI-8134 to pick up the upside of movement control and rapid trigger capacity. For position look at, the ADLINK PCI-8124 Encoder Card gives two strategies: direct capacity or variable interim. The PCI-8124 additionally gives the assortment of mapping capacity among comparator and trigger yield. The comparator condition can be related with lock signal, TTL info, and EA/EB signal.
The ADLINK PCI-8124 Encoder Card can be used with a Windows DVM driver. This driver allows users to utilize the DLL function library to create the application. This Encoder Card supports PCI-X (3.3V) and PCI (5V) slots.
The PCI-8124 Encoder Card uses a FPGA and FIFO to help minimize CPU loading for the host PC. All contrasting focuses will naturally load into FIFO and be contrasted with the inside comparators. Accordingly, clients do not need to use software. Clients will not have to stress over commotion unsettling influence using a computerized channel. It is possible for the clients to switch this programming control in the way they want due to the movable pulse width. Furthermore, the connection among trigger output and comparator is commonly relating. In the end, the amount of trigger yield heartbeat will be included and put away with the trigger counter.
| Model | PCI-8124 |
|---|---|
| Manufacturer | ADLINK Technology Inc. |
| Type | Encoder Card |
| Channels | 4 |
| Maximum Trigger Pulse Frequency | 1 MHz |
| Main Chip | ACTEL A3P1000 |
| Reference Clock | 40 MHz |
| Dimensions | 151 x 107 mm. |
| Connector | 50-pin SCSI-type connector |
| PCI-8124 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PCI-8124:
ADLINK PCI-8124 Frequently Asked Questions
Question: What is the trigger pulse width of the PCI-8124?
Answer: The trigger pulse width of the PCI-8124 is 0.1µs to 3.2765ms and is software programmable.
Question: What is the resolution of the internal timers on the ADLINK PCI-8124?
Answer: The resolution of the internal timers on the ADLINK PCI-8124 is 14-bit.
Question: Which modes are supported by the encoder counters on the PCI-8124?
Answer: The following modes are supported by the encoder counters on the PCI-8124: OUT/DIR, CW/CCW, and AB phase x1/2/4.
Question: Is the ADLINK PCI-8124 Plug and Play compliant?
Answer: Yes, the ADLINK PCI-8124 is completely Plug and Play compliant.
