AMETEK 3PCI

5/5 | 13 ratings

Modular Systems > AMETEK > 3PCI Series

Part Number AMETEK 3PCI
Manufacturer/Brand AMETEK
Description: AMETEK 3PCI 50/60 Hz Line Frequency Trigger Power Controller
Available | 1-2 Week Lead Time
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


AMETEK 3PCI Trigger Power Controller

The Robicon/AMETEK 3PCI (Part Number: R460C17.25) Trigger Power Controller delivers three-phase power to resistive and inductive loads. 3PCI stands for three-phase, cosine intercept. The 3PCI uses unlimited firing angle resolution for exact SCR control. This controller can function with many types of input signals and line voltages. Several features of this model include: 50/60 Hz functioning without necessary modifications, input isolation from ground, and a soft-start function.

is utilized for remotely setting off the recorder by means of a helper contact on an insurance transfer or engine starter. The advanced input must have a DC power supply within the range of 20 – 148V associated remotely. The extremity of the terminals must be watched. When the contact being observed is shut, a maximum of 10 mA will course through it. The 'outer trigger' must be empowered from the Display Station for outside activating to work. The information can be set for edge or level affectability. When all the important associations have been made, the framework is turned on by applying power and moving the supply flip switch, which can be found on the mounting plate inside at the base of the divider mounting unit, and inside the rackmounting unit at the front right. If the battery alternative is fitted, there will be a second switch.

The inspecting rate, channel marks, and scaling and different parameters, may have been set at the processing plant. If these parameters need to be changed, the Display Station must be associated with the 'Modified' plug on the mounting section.

ModelAMETEK 3PCI
ManufacturerASIRobicon/AMETEK
TypeTrigger Power Controller
Line Frequency50/60 Hz
Phase-firing time base0 to 180 degrees conduction per SCR
Controls (pots)3
Control signal input impedance250 Ohms, 0.5 watt standard
Weight40 to 231 lb (based on current rating)
WarrantyOne Year Warranty
AMETEK 3PCI ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

AMETEK 3PCI Frequently Asked Questions



Question: What is the purpose of the three-phase current limit feature on the 3PCI?



Answer: The three-phase current limit feature on the 3PCI stops the output current of an SCR power controller from going over a predetermined current level maximum.



Question: What is the input signal of the AMETEK 3PCI?



Answer: The AMETEK 3PCI has an input signal of 0-1.5 V minimum to 0-15 V maximum.



Question: What is the voltage of the AMETEK 3PCI?



Answer: The voltage of the AMETEK 3PCI is 480 Volts.
