Keysight U4301A PCIe Analyzer
The U4301A PCIe Analyzer is manufactured by Agilent/HP/Keysight. The Keysight U4301A PCIe Analyzer is compatible with all PCI Express applications, starting from Gen 1 to Gen 3 with speed ranging from 2.5 GT/s to 8 GT/s. The Keysight U4301A can capture and decode PCI Express data, then show it into a viewing window. The U4301A offers a capture buffer of 4 GB per module and link width support from x1 to x16 lanes.
The Keysight U4301A comes with a PCIe analysis tool that offers complete performance analysis of data, as well as of response time. To configure the Keysight U4301A PCIe Analyzer, the end-user will choose the number of lanes for testing and the software license for the suitable Gbps application. The U4301A performs easy and state-based triggering. The latest triggering modes can easily support a single event trigger. The state-based triggering consists of a trigger sequence backed by 4 states.
The Keysight U4301A PCIe Analyzer has influential hardware qualities that make capturing crucial events simple. For large recordings, it offers a large capturing buffer. The Keysight U4301A has LEDs to display the status of the lane and speed to quickly understand the current link’s status. The U4301A PCIe Analyzer can operate at a maximum of 40 °C. The host computer should have 1 GHz of minimum speed and 1.5 GB of available disc space. Microsoft Internet Explorer 7 or above is supported.
Model | U4301A |
---|---|
Manufacturer | Keysight Agilent HP |
Series | AXIe Analyzers |
Type | PCIe Analyzer |
Link Width | Support x1 through x16 lanes |
Compatible Models | M9502A or M9505A |
Minimum Trigger Duration | 20 ns |
Available Disc Space | 1.5 GB |
OS | Microsoft Internet Explorer 7 or greater |
Warranty | 2-3 Year Warranty |
U4301A Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
