M3202A
Modular Systems > Keysight Agilent HP > PXI Arbitrary Waveform Generators
Description: | M3202A, 400 MHz, 1 Gsa/s, PXIe Arbitrary Waveform Generator |
Need an Official Quote?
Or speak to a sales representative for additional information:
Keysight M3202A PXIe Arbitrary Waveform Generator
The M3202A PXIe Arbitrary Waveform Generator is manufactured by Agilent/HP/Keysight. The Keysight M3202A is an efficient Arbitrary Waveform Generator possessing high bandwidth and high performance. The Keysight M3202A PXIe Arbitrary Waveform Generator works in combination with the generation of advanced waveforms, producers of embedded functions, modulator of phase, frequency, and amplitude. This combination is utilized in generation of IF signals and broadband. The Keysight M3202A PXIe Arbitrary Waveform Generator possesses ease of use.
The Keysight M3202A is embedded with high precision function generators with a frequency resolution of 45 bit and a phase resolution of 24 bit. This PXIe Arbitrary Waveform Generator supports DC, square, sinusoidal, and triangular waveforms. The Keysight M3202A PXIe Arbitrary Waveform Generator provides a maximum of 8 reconfigurable inputs/outputs for advanced marking and triggering. The M3202A provides a high-quality output signal and low noise levels. With an onboard RAM of 2 GB, the Keysight M3202A additionally has an output frequency of 400 MHz.
The Keysight M3202A PXIe Arbitrary Waveform Generator comes with HVI technology (hard virtual instrumentation) and graphical programming technology (FPGA), resulting in high performance, along with ease for the end user. Several programming languages that can be used with the M3202A include C++, Python, MATLAB, LabVIEW, and other common programming languages. The M3202A PXIe Arbitrary Waveform Generator has four function generators that supports four types of waveforms, 0 to 400 MHz frequency range, 45 bits of frequency resolution, a phase range of 0 to 360 degrees, and a phase resolution of 24 bits.
Model | M3202A |
---|---|
Manufacturer | Keysight Agilent HP |
Series | PXI Arbitrary Waveform Generators |
Type | PXIe Arbitrary Waveform Generator |
Channels | 4 |
Output Speed | 1000 MSa/s |
Output Resolution | 14 bits |
Bandwidth | DC-400 MHz |
Onboard RAM | 2 GB |
Size | 1 PXIe slot |
Warranty | 2-3 Year Warranty |
M3202A Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
