Keysight M9211A PXI-H IF Digitizer
The Keysight M9211A is a PXI-Hybrid 3U IF single-channel Digitizer, equipped for catching signals up to 3 GHz and working at a speed of up to 4 GS/s. These features help lessen procurement and test times. The M9211A UWB Digitizer accompanies a coordinated memory of up to 512 MBytes. Perfect for high frequency signal capture in applications such as aerospace and defense, radar test, and applications with wideband signal capture needed. The M9211A is a more affordable option in contrast to the M9202A 12-bit IF digitizer.
The M9211A has a MMCX female connector that is utilized for the outside reference or the contribution of the outer clock flag. The outside reference clock frequency is 10 MHz. The frequency range of the outside clock flag is 200 MHz at 2 GHz. Regardless, the abundancy must be 500 mV pk-pk or higher. The greatest DC voltage must not surpass ± 5 V. This model is confirmed by utilizing it to trigger and show a flag from a capacity generator. The trigger must be steady, and the frequency and abundancy of the flag must compare to that built up in the generator.
By tapping on the 'Begin SFP' button, it will give control of the Keysight M9211A Digitizer to individual test and other working controls. This digitizer has various automatic interfaces that permit simple joining into existing test situations and can be easily programmed. These include Windows® Vista, SP1 and SP2 (32-bit and 64-bit), Business, Ultimate, Enterprise, Home Basic, and Home Premium.
| Model | M9211A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Type | PXI-H IF Digitizer |
| Slot Requirements | 1 |
| Channels | 1 |
| Bandwidth | 3 GHz |
| Sampling Rate | 4 GS/s maximum |
| Size | 3U |
| Weight | 0.8 lb. |
| M9211A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for M9211A:
Keysight M9211A Frequently Asked Questions
Question: What is the onboard memory size of the M9211A IF Digitizer?
Answer: The onboard memory size of the M9211A IF Digitizer is 512 MSamples.
Question: Which type of coupling does the M9211A have?
Answer: The M9211A has DC coupling.
Question: Which acquisition modes are available on the Keysight M9211A?
Answer: The Keysight M9211A has sequence and single shot acquisition modes available.
