Keysight M9210A PXI-H High-Speed Digitizing Scope
The Keysight M9210A High-Speed Digitizing Scope permits multi-module synchronization because of the auto-synchronous bus framework ready to achieve picoseconds-level precision between various channels.
This Agilent Digitizing Scope has 10-bit resolution, up to 4 GS/s sampling rate, and more than 1 GHz of data transfer capacity. These features ensure this modular scope is appropriate for computerized test frameworks that need scope type estimations on expedient signs. The installed extension type highlights incorporate selectable 50ω/1MΩ information impedance and AC/DC coupling, full-scale run, balance control, and exceptional activating capacities. Moreover, it is conceivable to accomplish multichannel synchronization by gathering picoseconds-dimension of precision between a few cards. These digitization extensions are intended to profit by the convenience from a PC for applications that need a major number of channels and mechanized test purposes, contrasted with oscilloscopes that basically streamline the human interface.
The Agilent M9210A incorporates an Agilent MD1 delicate front board (SFP) graphical interface. This basic programming application can be utilized to control, confirm the usefulness, and investigate the capacities of the Agilent digitizers. The MD1 SFP contains some standard extension estimations like mean, RMS, min/max, pk-pk adequacy, overshoot, rise/fall time, slew rate, and numerous others.
The Agilent MD1 delicate front board programming has two principle windows: the obtaining parameters to control the module and the gained waveform show. The Agilent M9361A has diverse trigger qualities of up to 256 MS/channel memory and highlights a programmed synchronization transport framework with picosecond precision for synchronization of numerous modules.
| Model | M9210A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Type | High-Speed Digitizing Scope |
| Sampling Rate | 4 GS/s maximum |
| Bandwidth | 1.4 GHz |
| On-board Memory | 256 MSamples/channel maximum |
| Resolution | 10-bit |
| Size | 3U |
| Weight | 0.9 lb. |
| M9210A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for M9210A:
Keysight M9210A Frequently Asked Questions
Question: Which type of coupling is available on the Keysight M9210A?
Answer: The Keysight M9210A has selectable AC/DC coupling.
Question: How many analog input channels does the M9210A Digitizing Scope have?
Answer: The M9210A Digitizing Scope has 2 analog input channels.
Question: Which applications can the Agilent M9210A be used for?
Answer: The best applications for the Agilent M9210A are wideband applications like radar, semiconductor testing, aerospace and defense, and wireless communication.
