NI 781587-01 Manual VNA Calibration Kit
Part number 781587-01 is a Calibration Kit from National Instruments. This Calibration Kit is recommended for scenarios where manual, port one reflection calibration is desired. The connector configuration of part number 781587-01 is designed to match K-type ports. This Manual VNA Calibration Kit can only be used for manual testing, verification, and calibrations. Consider acquiring NI 782364-01 if you are looking for completing the entire calibration process automatically.
You can achieve the optimum temperature of the compatible PXIe-5630 or PXIe-5632 Vector Network Analyzer (VNA) for calibration by allowing it to warm up for 45 minutes. After completion of the calibration process through the NI 781587-01, your Vector Network Analyzer should display CORR measuring state through the NI-VNA SFP. This Manual VNA Calibration Kit fully supports National Instruments VNA, which is a software application that provides a visual interface for the configuration and calibration of the Vector Network Analyzer.
| Model | 781587-01 |
|---|---|
| Manufacturer | NI |
| Type | Calibration Accessory |
| Calibration Type | Manual |
| Connection | K-type |
| Compatible Models | PXIe-5630 and PXIe-5632 |
| Warranty | 2-3 Year Warranty |
| 781587-01 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
