National Instruments 785621-02 cRIO-9047 8-Slot CompactRIO Controller
The National Instruments 785621-02 (cRIO-9047) is an 8-slot CompactRIO embedded controller engineered for high-performance industrial control, real-time data acquisition, and Time-Sensitive Networking (TSN) applications. Featuring protective conformal coating for enhanced environmental durability, the controller is driven by an Intel Atom E3940 quad-core processor running at a 1.6 GHz base frequency (up to 1.8 GHz burst) with 2 MB of dedicated L2 cache. Operating under deterministic 64-bit NI Linux Real-Time, the system is backed by 4 GB of low-voltage DDR3L DRAM (delivering peak bandwidth up to 12.8 GB/s) and 4 GB of onboard nonvolatile storage for reliable embedded application execution and data logging across eight integrated C Series I/O slots.
To enable user-programmable, ultra-low latency processing, custom hardware triggering, and inline digital signal processing, the cRIO-9047 incorporates a Xilinx Kintex-7 7K70T FPGA. The reconfigurable fabric provides 82,000 flip-flops, 41,000 6-input LUTs, 240 dedicated DSP slices, and 4,860 kbits of block RAM, supported by 16 high-throughput DMA channels for fast, direct memory access between the FPGA and real-time processing cores.
For multi-device synchronization and industrial networking, the controller features two Gigabit Ethernet ports supporting 10/100/1000Base-T auto-negotiation over distances up to 100 meters. Both ports support Time-Sensitive Networking (TSN) mechanisms compliant with IEEE 802.1AS-2011 and IEEE 1588-2008 standards, achieving sub-microsecond timing synchronization accuracy across distributed systems, as well as full support for GigE Vision camera streams. Serial and peripheral options include an RS-232 serial port (baud rates up to 115.2 kbps with configurable parity and flow control, plus ±24 V Ring Indicator overvoltage protection), a 60 VDC continuously isolated RS-485 port supporting 2-wire, 4-wire, and auto-2-wire modes up to 230.4 kbps, and two USB host ports for external storage or diagnostic expansion. Built for continuous operation in extreme industrial conditions, the module withstands extended operating temperature ranges spanning -40 °C to 70 °C.
| Model | 785621-02 |
|---|---|
| Model Name | cRIO-9047 |
| Part Type | 1.60 GHz Quad-Core CPU, 4 GB DRAM, 4 GB Storage, -40 °C to 70 °C, Kintex-7 70T FPGA, 8-Slot CompactRIO Controller |
| Number Of Ethernet Ports On Controller | 2 |
| TSN Enabled | Synchronization |
| Slot Count | 8 |
| Conformal Coated | Yes |
| FPGA | Kintex-7 70T |
| GigE Vision Support | Yes |
| Operating Temperature Range | -40 °C To 70 °C |
