National Instruments 781337-01 Analog Input Module

The part number 781337-01 from National Instruments is the identifying part number for the PXIe-4300 Isolated analog input module. It has a 16-bit ADC resolution per channel, thus enabling accurate data acquisition. This instrument does not have missing codes to ensure reliable output at all times. This product’s highest per-channel sample rate is 250 kS/s so it can be applied to many diverse applications since there is no minimum sampling rate requirement. The accuracy of timing has been maintained at 50 parts per million of the sample rate with an additional timing resolution of 10 ns thus ensuring very accurate time measurements.

Input coupling is DC voltage ranges for each channel that may be set by software 10 V, 5 V, 2 V, or 1 V. This means that the common mode rejection ratio (CMRR) changes accordingly with the range of voltages that it covers achieving 95 dB at 10 Volts, 100 dB at five volts and finally attaining up to 105 dB at either 2 Volts or 1 Volt thereby canceling noise commonly present in these low frequency signals up to below 60 hertz. The bandwidth of the is equal to approximately 520 kHz and the low pass filtering options are selectable for every channel using software between 10 and 100 kHz with an option to switch them off as well.

These power supply requirements are aimed at serving PXIe systems that require +3.3 Volts at 2 W and +12 Volts at 8.8 Watts respectively which will make its use possible in such systems as PXIe.With a measurement of 16 cm by 10 cm and a weight of 148g, the module is compact enough to be accommodated in any current system as it meets the standard 3U PXIe dimension requirements.

The PXIe-4300 has been designed only for indoor operation and has a pollution degree of 2. The product works well within ambient temperatures ranging from about 0 to 55 degrees Celsius and relative humidity levels between 10% to 90%, non-condensing while at a maximum altitude of two thousand meters (800 mbar) at 25 degrees Celsius.

Part Number781337-01
Model NamePXIe-4300
Part TypeAnalog Input Module
Number of Channels8
Maximum Sample Rate16 bits
Maximum Input Voltage300 V
Anti-Alias FilterNo
Selectable Low-Pass Filter10 kHz, 100 kHz
Bus TypePXI Express
Module Width1
