DAQCard-6715

4.9/5 | 19 ratings

Modular Systems > National Instruments > DAQCards

Part Number DAQCard-6715
Manufacturer/Brand National Instruments
Description: DAQCard-6715, 8 Voltage Outputs, 12 bits, Multifunction I/O Device
In Stock | Ships in 5-10 Days
(expedited shipping options available)
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments DAQCard-6715 Multifunction I/O Device

Featured with 2 counters/timers and 8 digital I/O lines, the DAQCard-6715 (Part Number: 778146-01) is a PCMCIA Multifunction I/O Device from National Instruments. This device comes with 8 analog outputs (12-bit) and can operate with an update rate up to 1 MS/s on each analog output channel. The NI DAQCard-6715 offers full external clocking and digital triggering functionality. Moreover, it can easily be configured through DAQmx for instant and precise measurements. This device is designed to operate as a Plug and Play device. Thus, you can add or remove this device from a running system without causing any interruptions. This Multifunction I/O Device comes equipped with a dedicated, 12-bit DAC per channel for voltage outputs. The NI DAQCard-6715 is an easy-to-configure device, since it doesn’t have any jumpers, DIP switches, or potentiometers. You can have this device configured or calibrated easily through software.

The NI DAQCard-6715 Multifunction I/O Device is designed for 5 Volt PC card slots that are commonly found in routine desktop computers. The eight voltage output channels on this device can be accessed through the I/O connector. Users can select a different reference for analog output channels through software. The eight digital I/O incorporated in this device are designed to support a broad range of routine applications. Each digital I/O line can be configured for input or output. When the DAQCard-6715 initiates, all the digital I/O lines go to their default mode which is high impedance. For timing and synchronization related applications, this device capitalizes on the DAQ-STC.

DAQCard-6715 Obsolete Status has been announced by National Instruments, but the device will still be available for purchase and repairs by Apex Waves.

ModelDAQCard-6715
ManufacturerNational Instruments
Part Number778146-01
TypeMultifunction I/O Device
Analog Output Channels8 voltage outputs
Analog Output Resolution12 bits, 1 in 4,096
FIFO Buffer Size8,192 samples
Type of DACSerial, multiplying
DimensionsType II PC Card
I/O Connector68-pin female Honda connector
Warranty2-3 Year Warranty
DAQCard-6715 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the DAQCard-6715:

18669.5, 186695B-01, 186695C-01, 186695D-01, 778146-01

  DAQCard-6715 PDF Manuals

Driver Downloads for DAQCard-6715






OS Compatibility:
Win XP 32-bit, Win 7 32-bit, Win 10 32-bit

 Download Version
