PCIe-6537B

Modular Systems > National Instruments > DIO Series

Part Number PCIe-6537B
Manufacturer/Brand National Instruments
Description PCIe-6537B 32-Channel, 50 MHz Digital I/O Device

Speak to a sales representative for pricing & lead time:


National Instruments PCIe-6537B Digital I/O Device

The PCIe-6537B is an efficient Digital I/O Device designed by National Instruments. This device is available under part number 782631-01. The PCIe-6537B features various options for digital inputs and outputs for PC-based systems. This device is equipped with programmable input terminals. These terminals remove glitches and noise from incoming signals. These filters are also compatible with digital switches and relays. Another special feature of the PCIe-6537B is the digital watchdogs, which provide a fail-safe mechanism to prevent permanent damage of the device.

The PCIe-6537B Digital I/O Device is equipped with 32 data channels. These channels can stream continuous data. This device also incorporates six PFI channels. These channels have per channel direction control. This device does not have dedicated input or output channels. The range of input voltage in this Digital I/O Device is -1 to +6 volts. The output voltage range is 0 to +5 volts.

The PCIe-6537B also features triggering; eight trigger channels are available for this purpose. These channels support RTSI and PXI type bus. This device has a clock rate up to 50 MHz. The PCIe-6537B generates signals of 2.5 and 3.3 volts. The maximum drive strength is +16 mA and +32 mA respectively. This device also has an onboard clock, with a frequency from 48 Hz to 50 MHz. The maximum toggling rate for the data channels is 25 MHz.

The PCIe-6537B Digital I/O Device supports NI-DAQmx driver software. The older versions of this software before version 9.6.1 are not supported. The NI-DAQ features a programming interface with various ADEs. Supported application software types are NI LabVIEW, NI LabWindows, and Microsoft Visual Studio.

ModelPCIe-6537B
ManufacturerNational Instruments
Part Number782631-01
TypeDigital I/O Device
Number of Data Channels32
On Board Clock Frequency Range48 Hz to 50 MHz
Onboard Memory Size2,048 samples (S)
Power Requirements+3.3 VDC, +12 VDC - 1A, 225 mA
Power Consumption6 W
Dimensions7.13 in. × 0.85 in. × 4.93 in.
Weight0.24 lb.
Driver SoftwareNI-DAQmx Version 9.6.1 or later
WarrantyOne Year Warranty
PCIe-6537B ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCIe-6537B Frequently Asked Questions



Question: Does the PCIe-6537B have selectable voltage levels?



Answer: Yes, the PCIe-6537B features selectable voltage levels.



Question: When using the NI PCIe-6537B in MATLAB, I get a blue screen. I do not have this problem when using LabVIEW or MAX. What could the problem be?



Answer: If you’re getting a blue screen when using NI PCIe-6537B in MATLAB, but not in other software programs, it sounds like there is a problem with that software. You would need to contact their manufacturer.



Question: How many channels does the PCIe-6537B have?



Answer: The PCIe-6537B is a 32-channel digital input/output device.

PCIe-6537B Technical Specifications:


Manufacturer:National Instruments
Model:PCIe-6537B
Part Number:782631-01
Type:Digital I/O Device
Repair Evaluation:$150
