National Instruments PXIe-7911 PXI FlexRIO Coprocessor Module
The PXIe-7911 is a PXI FlexRIO Coprocessor Module. The manufacturer of the PXIe-7911 module is National Instruments. National Instruments has launched the NI PXIe-7911 module with the part number 785172-01. The PXIe-7911 module is a member of the FlexRIO products by National Instruments. The NI PXIe-7911 module contains an FPGA that can be activated by LabVIEW software. The Xilinx Vivado is also used for programming additional tasks in the FPGA controller.
The NI PXIe-7911 PXI FlexRIO Coprocessor Module is built with a KU035 FPGA. The FPGA in the PXIe-7911 module can be programmed with Xilinx Vivado to offer additional signal-processing tasks for PXI Express systems. The NI PXIe-7911 module is an x8 Gen 3 PXI module. The PXIe-7911 has peer-to-peer streaming capabilities. The NI PXIe-7911 is fabricated with a block RAM (BRAM) of 19 Mbit and 0 GB of dynamic ram (DRAM). National Instruments provides 1700 DSP slices within the PXIe-7911 FlexRIO Coprocessor Module. This module does not have auxiliary I/O.
The NI PXIe-7911 FlexRIO Coprocessor Module is built with 50780 FPGA slices. The PXIe-7911 supports PXI triggering, as well as PXI star triggering functions. The National Instruments PXIe-7911 module is manufactured with 60 DMA channels. The NI PXIe-7911 module can be paired with other PXI devices like PXI Vector Signal Transceivers for additional functionalities. The PXIe-7911 PXI FlexRIO Coprocessor Module works with moderate processing for signal-based applications. The NI PXIe-7911 module is compatible with chassis that can function with a power capacity of 58 W or more.
| Model | PXIe-7911 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 785172-01 |
| Type | PXI FlexRIO Coprocessor Module |
| FPGA Type | Kintex UltraScale KU035 |
| DRAM | 0 GB |
| BRAM | 19 Mbit |
| FPGA Slices | 50780 |
| Dimensions | 7.4 in. × 5.1 in. |
| Weight | 6.7 oz. |
| PXIe-7911 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
