Part Number PCIe-8237
Manufacturer/Brand National Instruments
Description: PCIe-8237, 2-Port, Frame Grabber Reconfigurable Device
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments PCIe-8237 Frame Grabber Reconfigurable Device

The PCIe-8237 (Part Number: 782525-01) is a Frame Grabber Reconfigurable Device that comes with an IEEE 802.3af standard. This standard characterizes a convention for transmitting force and information motions over a framework generally named Power over Ethernet (PoE). An appraised Ethernet port of 48 VDC for a PoE-empowered switch transmits control over unshielded contorted combined cabling to finish gadgets of 12.95 W. The more up to date IEEE 802.3af (PoE +) determination will expand the base measure of intensity accessible at an end gadget to upwards of 59 W and empower transmission over speedier 1000BASE-T gigabit Ethernet framework. With 802.3af, a PoE-empowered gadget is capable to convey or get control over the four curved match copper wires of a CAT 3 (least) Ethernet link in two unique setups to convey power, information, or both. In the NI PCIe-8237 Frame Grabber Device, the power can be communicated either on the two sets of wires that direct information (elective A), or on the two unused sets (elective B). IEEE 802.3at requires at least CAT 5e yet takes into account the capacity to be transmitted on every one of the four sets to expand the aggregate sum of intensity accessible to end gadgets.

This Frame Grabber Device comes with a PSE function that provisions control over the wound combine and controls the location, order, and shutdown exercises of a controlled gadget at the opposite end of the link. The PCIe-8237 also has 2 Gigabit Ethernet Interface ports, and a GigE Vision Camera Interface.

ModelPCIe-8237
ManufacturerNational Instruments
Part Number782525-01
TypeFrame Grabber Reconfigurable Device
Number of Ports2 Ports
FPGASpartan-6 LX25 (I/O Only)
Speed10, 100, 1000 Mbps
Camera InterfaceGigE Vision
StandardIEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T
I/O ConnectorsRJ45
PCI Express Compliance1.1
Bus PowerPower over Ethernet (PoE) (IEEE 802.3af Compatible)
LEDs4 (Two LEDS per Ethernet port)
Power Requirements+12 V, +3.3 V - 0.92 A, 0.74 A
Dimensions4.4 in. × 6.6 in.
Weight0.38 lb.
Driver SoftwareNI-IMAQdx 4.1
NI Vision
Warranty2-3 Year Warranty
PCIe-8237 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PCIe-8237:

152204A-01L, 152204A-02L, 152204B-01L, 152204B-03L, 782523-01, 782525-01

National Instruments PCIe-8237 Frequently Asked Questions
