National Instruments PCIe-8253 Frame Grabber Device

The PCIe-8253 (Part Number: 781107-01) is an IEEE 1394a and IEEE 1394b interface compliant with RoHS for PC-based frameworks. If the user wishes to link this device to an IEEE 1394a camera, they eitherneed a 6-pin to 9-pin cable or a 6-pin to 9-pin adapter. The PCIe-8253 is well-suited for machine vision applications with high information rates. The interface nourishes and obtains information from cameras through three IEEE 1394 camera input ports. The center points associated with any of the ports permit acquisition from different cameras. The NI PCIe-8253 device gives an easy approach to examine from a few edges. With two IEEE 1394 ports, the user can straightforwardly interface two cameras to a board. The user can interface up to 16 IEEE 1394 cameras to each board with the expansion of an IEEE 1394 center point. IEEE 1394 is a standard bus, which implies there is a wide assortment of cameras that can interface with the NI PCIe-8253 Frame Grabber Device.

With more than 300 cameras accessible to finish an application, the user’s decisions run from minimal effort, low-determination sensors to an elite sensor. There are also strength cameras, such as infrared and lines-can. Furthermore, as new enhanced modern IEEE 1394 cameras enter the commercial center, the user can update their framework with the most recent cameras available without having to change the picture obtaining board or the product. By utilizing IEEE 1394 picture securing, the NI PCIe-8253 enables the user to utilize the sensor that is ideal for their application.
