National Instruments 780570-01 GPIB-USB Interface Module
The National Instruments 780570-01 (GPIB-USB-HS) is a high-speed controller device that converts any USB port into a fully functional IEEE 488.2 GPIB controller. Utilizing a High-Speed USB 2.0 interface, it delivers data transfer rates up to 7,230 kB/s while supporting the complete set of IEEE 488.2 standards. Its standard female IEEE 488 connector on the front panel allows for direct control of up to 14 instruments simultaneously without requiring an internal GPIB expansion card or dedicated host-side GPIB cables. Operating across a 0°C to +55°C temperature range, the compact unit draws power directly from the USB bus, eliminating the need for an external power supply.
This specific variant (780570-01) is engineered specifically for compatibility with Mac OS environments, bundled alongside the necessary NI-488.2 driver software and compliance documentation to ensure reliable communication with third-party instruments. By bridging legacy test equipment—such as oscilloscopes, multimeters, and signal generators—with modern Mac OS workstations, it simplifies system configuration and reduces hardware overhead in space-constrained setups.
Test and automation engineers rely on the 780570-01 across laboratory, research, and production-line verification environments. Its plug-and-play USB connectivity and bus-powered design make it ideal for portable diagnostic setups, automated test equipment (ATE) integration, and modernizing legacy instrumentation suites without modifying existing hardware infrastructure.
| Model | 780570-01 |
|---|---|
| Part Number | 780570-01 |
| Part Type | GPIB-to-USB adapter |
| Host Interface | USB 2.0 Hi-Speed |
| GPIB Ports | One IEEE 488 female |
| Max Throughput | 7230 kB/s |
| OS Support | Mac OS only |
| Power Source | USB bus-powered |
| Operating Temp | 0 °C to 55 °C |
| Max Devices | 14 instruments |
