National Instruments 783007-01 PCI-GPIB Instrument Control Device
The National Instruments 783007-01 (PCI-GPIB) is a high-performance IEEE 488 controller board designed to interface stand-alone instrumentation with PCI-based host computers and industrial control systems. Powered by dedicated hardware for high-speed data transfers, the board achieves IEEE 488.1 3-wire handshake transfer rates up to 1,536 kB/s and high-speed HS488 handshake rates up to 7,885 kB/s (7,230 kB/s nominal maximum baud rate). Throughput is optimized via an integrated 1,024-word FIFO buffer and the fast REP-INSW interrupt service routine (ISR) transfer method, delivering sustained transfer speeds exceeding 1 MB/s across full IEEE 488 cabling distances while bypassing slower conventional DMA methods.
Physical connectivity on the board features a high-density Mini-GPIB (Micro D-Sub) front connector interface, which converts to a standard 24-pin IEEE 488 GPIB connector via a specialized adapter cable. The board utilizes Universal PCI keying to support both 3.3 V and 5 V PCI bus architectures, incorporating true Plug and Play capability that automatically configures system base addresses and interrupt requests (IRQ) without requiring manual DIP switch or jumper configurations. Power is drawn directly from the host system's +5 V supply rail, operating at a typical current consumption of 300 mA (450 mA maximum).
Engineered in a compact full-height PCI form factor measuring 12.0 cm × 6.44 cm (4.7 in. × 2.5 in.), the board fits easily into standard PC expansion slots. Designed for broad platform flexibility across legacy and modern systems, the module includes driver software support for Windows and DOS operating environments. The device operates reliably across an ambient temperature range of 0 °C to 55 °C (-20 °C to 70 °C storage) with non-condensing relative humidity tolerances of 10% to 90% during operation and 5% to 95% in storage.
Part Number |
783007-01 |
|---|---|
Model Name |
PCI-GPIB |
Part Type |
PCI, IEEE 488 GPIB Instrument Control Device |
Bus Connection |
PCI |
Low Profile |
No |
Onboard GPIB Analyzer |
No |
Supported Operating System |
Windows |
Front Connection Type |
Mini-GPIB(1) |
Operating Temperature Range |
0 °C To 55 °C |
Maximum Baud Rate |
7230 kB/s |
