National Instruments PXIe-5668 Vector Signal Analyzer
The PXIe-5668 (Part Numbers: 783156-01, 783124-01, 783156-02, 783124-02, 783156-03, 783124-03) is a 1-Channel, 26.5 GHz maximum, Vector Signal Analyzer from National Instruments. The instrument comes with advanced technology, so users can carry out measurements that require high-performance accuracy. It allows measurements for applications involving signal intelligence and radio frequency, as well as the characterization of integrated circuits. The instrument can additionally be used for RADAR testing. This Analyzer has the capability to operate in combination with a preamplifier to enhance the sensitivity and dynamic range of the instrument. The NI PXIe-5668 Vector Signal Analyzer enables speedy measurements, making it the perfect choice for analysis needs in the mass manufacturing industry.
The National Instruments PXIe-5668 Vector Signal Analyzer comes with 2 GB of built-in memory for different RF measurements and analysis. The frequency range for RF spectrum analysis is from 20 Hz to 26.5 GHz maximum. The average value for the noise level of the device is -166 dBm per hertz. It is between the frequency ranges of 300 MHz to 1.7 GHz. The PXIe-5668 Analyzer does not have a built-in preamplifier.
The NI PXIe-5668 has the capability to measure intermodulation distortion and adjacent channel power, along with the magnitude of the error vector. Various accessories are also available to help the user quickly set up the instrument for different testing needs. The PXIe-5668 Vector Signal Analyzer features built-in IF signals to IQ data converter. This model offers users a wide bandwidth and maximum flexibility to handle challenging tasks.
| Model | PXIe-5668 |
|---|---|
| Part Numbers | 783156-01, 783124-01, 783156-02, 783124-02, 783156-03, 783124-03 |
| Manufacturer | National Instruments |
| Type | PXI Vector Signal Analyzer |
| Third-Order Intercept | +25 dBm |
| Onboard Memory Size | 2 GB |
| Bandwidth | 80 MHz, 200 MHz, or 765 MHz |
| Channels | 1 |
| Connector | SMA |
| Warranty | 2-3 Year Warranty |
| PXIe-5668 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXIe-5668:
152637-01, 152638-01, 152639-01, 152640-01, 152641-01, 157378A-01L, 157378B-01L, 158764B-01L, 196945D-01L, 198265D-01L, 200147A-01, 783124-01, 783124-02, 783124-03, 783124-04, 783124-05, 783156-01, 783156-02, 783156-03, 783546-01, 783546-02, 783546-03, 783547-01, 783547-02, 783547-03, 783901-01, 783901-02, 783901-03, 783902-01, 783903-01, 783937-02, 783937-04, 783937-08, 784640-01, 784679-01, 785864-01, 785865-01, 785866-01, 785867-01, 785868-01, 785869-01, 786160-01, 786161-01, 786784-01, 786785-01, 786786-01, 786787-01, 786788-01, 786789-01
National Instruments PXIe-5668 Frequently Asked Questions
Question: What are the differences between the multiple part numbers for the PXIe-5668?
Answer: The PXIe-5668 has multiple part numbers with varying specifications. First, part number 783156-01 has 80 MHz bandwidth and 20 Hz to 14 GHz frequency range. Part number 783124-01 has 80 MHz bandwidth and 20 Hz to 26.5 GHz. Part number 783156-02 has 200 MHz bandwidth and 20 GHz to 14 GHz frequency range. Next, part number 783124-02 has 200 MHz bandwidth and 20 Hz to 26.5 GHz frequency range. Part number 783156-03 has 765 MHz bandwidth and 20 Hz to 14 GHz frequency range. Lastly, part number 783124-03 has 765 MHz bandwidth and 20 Hz to 26.5 GHz frequency range.
Question: Does the NI PXIe-5668 VSA have a preamplifier?
Answer: No, none of the PXIe-5668 VSA does not have a preamplifier.
Question: What modules comprise the NI PXIe-5668?
Answer: The NI PXIe-5668 is comprised of the PXIe-5606 RF Signal Downconverter, PXIe-5624 IF Digitizer, and PXIe-5653 RF Analog Signal Generator.
Question: Which driver should be used with the PXIe-5668?
Answer: The NI-RFSA driver should be used with the PXIe-5668.
