National Instruments 788167-01 PXIe-8862 2.6 GHz 8-Core PXI Express Embedded Controller
The National Instruments 788167-01 (PXIe-8862) is a high-performance 3U PXI Express embedded controller designed for computationally intensive automated test, data acquisition, and hardware-in-the-loop (HIL) simulation applications. Powered by an 11th Gen Intel Core i7-11850HE 8-core processor operating at a 2.6 GHz base clock with 24 MB of Intel Smart Cache, the module delivers fast multi-threaded execution under a pre-installed 64-bit Windows 10 operating system. Memory is pre-configured with 16 GB of dual-channel DDR4-3200 SODIMM RAM (2 × 8 GB), while primary high-speed storage is provided by a removable 960 GB U.2 NVMe solid-state drive (SSD), enabling rapid field drive swaps, simplified maintenance, and secure data handling for classified or sensitive test setups.
The PXIe-8862 features high-bandwidth backplane integration via Gen 3 PCI Express link speeds up to 8.0 GT/s, supporting configurable backplane topologies including four x4 links or two x8 links. Front-panel peripheral and networking interfaces feature dual Thunderbolt™ 4 Type-C ports, two DisplayPort 1.4 video outputs, an RS-232 serial port, an optional IEEE 488 (GPIB) instrument control port, and optional TPM 2.0 hardware security support. Advanced networking capabilities are driven by dual Intel i225 2.5 GbE Ethernet controllers supporting low-latency data streaming and precise network timing.
Mechanically constructed as a 4-slot 3U PXI Express module (requiring one system slot plus three controller expansion slots), the assembly weighs 906 g (2.00 lb) with the removable drive installed. Engineered for high reliability in demanding rack environments, the controller operates across an ambient temperature range of 0 °C to 55 °C (-40 °C to 71 °C storage) with operational shock resistance rated to a 30 g peak (11 ms half-sine pulse) and operational random vibration immunity of 0.3 grms from 5 Hz to 500 Hz (2.4 grms non-operational).
| Model | 788167-01 |
|---|---|
| Model Name | PXIe-8862 |
| Part Type | PXIe, 2.6 GHz, 8-Core Processor, GPIB and No-GPIB Port Options, PXI Controller |
| CPU | Intel® Core™ i7-11850HE |
| Cache | 24 MB Smart Cache |
| Video | 2 DisplayPort 1.4 |
| PCI Express Link Speed | 8.0 GT/s |
| Thunderbolt 4 Ports | 2 Type-C |
| SuperSpeed USB (3.0) Ports | 2 Type-A |
| Ambient Temperature Range | 0 °C to 55 °C |
