NI-8260
Modular Systems > National Instruments > PXI Data Storage Modules
| Description: | NI-8260, 4-Drive, PXI Data Storage Module |
(expedited shipping options available)
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments NI-8260 PXI Data Storage Module
The NI 8260 (Part Number: 780980-01) high-speed Data Storage Module is created for use in PXI Express systems with four 2.5 inch SATA drives and the choice between hard-disk drives for more storage space or solid-state drives for more durability. This module is ideal for several different types of applications, such as extended data storage, field data acquisition, and signal record and playback. The NI-8260 module utilizes three slots of a PXI Express chassis, requiring a PXI Express peripheral slot and two following slots. This NI Data Storage Module offers high-speed data storage for applications involving a transportable high-speed data streaming solution.
The National Instruments NI 8260 PXI Data Storage Module has two types of configuration available: software RAID-0 and JBOD. RAID-0 is also known as striped and dispenses the information among the four disks without redundancy. The outcome is high data throughput and the most storage capacity possible. RAID-0 offers the highest performance attainable for streaming information to and from disk since it dispenses information equally across a set of hard drives. The RAID-0 configuration additionally does not accept drive failure. On the other hand, the JBOD configuration, otherwise known as spanned, connects the four drives together to make a single disk space. For the JBOD configuration, the information fills the first drive and continues through the following drives. JBOD does not implement redundancy and does not accept drive failure as well. Both configurations for the NI-8260 Data Storage Module are implemented through the Windows operating system.
NI-8260 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.
| Model | NI-8260 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 780980-01 |
| Type | PXI Data Storage Module |
| Hard Drives | 4 |
| Slot Requirements | 1 PXI Express module slot and 2 module expansion slots |
| Compatibility | CompactPCI Express spec component |
| Dimensions | 2.4 × 5.1 × 8.5 in. |
| Weight | 770 g (standard configuration) |
| Warranty | 2-3 Year Warranty |
| NI-8260 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for NI-8260:
196555A-01, 196555A-02, 196555A-03, 196555B-01, 196555B-02, 748134-01, 780980-01, 780981-01, 782090-01
National Instruments NI-8260 Frequently Asked Questions
Question: What type of SATA chipset does the NI-8260 have?
Answer: The NI-8260 has a Marvel 88SX7042 SATA chipset.
Question: What is the total storage capacity for the NI 8260 module?
Answer: The total storage capacity for the NI 8260 module is 1 TB minimum for HDD and 256 GB minimum for SSD.
Question: What is the part number for the 250 GB 2.5 in. SATA spare hard drive for the NI-8260?
Answer: The part number for the 250 GB 2.5 in. SATA spare hard drive for the NI-8260 is 781070-01.
Question: What type of hard disk drive interface does the NI 8260 have?
Answer: The NI 8260 has a Serial-ATA hard disk drive interface.
