National Instruments PXIe-2544 PXI RF Multiplexer Switch Module

The PXIe-2544 (Part Number: 780587-44) is a PXI RF Multiplexer Switch Module from National Instruments, with 8x1 terminated multiplexer technology. The NI PXIe-2544 RF Module comes with a built-in mechanism to offer the input frequency, with a minimum value of 10 Megahertz. The nominal value for the characteristic impedance of the module is 50 ohms. It is denoted by Z0. It enables the device to carry the RF signal up to 6.6 GHz. The instrument also has the capability to offer AC coupling. The maximum safe value for DC input voltage for the PXIe-2544 RF Module is ±8 volts.

The NI PXIe-2544 RF Multiplexer Switch Module features high-performance solid-state relays, which enable the fast switching mechanism for various application requirements. There are FET switches on the PXIe-2544. The module incorporates SMA connectors on the front panel. This enables the user to connect RF devices more conveniently. The value for maximum safe continuous RF power is +30 dBm when chassis power is on. Its value with chassis power off is +20 dBm. The NI PXIe-2544 has low values for insertion loss, which varies at different frequency levels. The value of the thermal coefficient for insertion loss (α) is 3,402 ppm/℃.

The NI PXIe 2544 offers a maximum switch operating time of 122 microseconds. Some applications also require additional time for normal operation of the module. It has the switch of the type of FET. The PXIe-2544 RF Multiplexer Switch Module weighs around 538 grams. This module has the dimensions of 8.5 L x 0.8 W x 5.1 H inches.

ModelPXIe-2544
Part Number780587-44
ManufacturerNational Instruments
TypePXI RF Multiplexer Switch Module
Banks1
Channels8
Switch Bandwidth6.6 GHz
Dimensions8.5 x 0.8 x 5.1 in.
Weight19 oz.
Warranty2-3 Year Warranty
PXIe-2544 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the PXIe-2544:

153942A-01L, 153942B-01L, 153942C-01L, 780587-44

National Instruments PXIe-2544 Frequently Asked Questions



Question: What is the minimum input frequency of the PXIe-2544?



Answer: The minimum input frequency of the PXIe-2544 is 10 MHz.



Question: What is the maximum safe DC input voltage for the NI PXIe-2544?



Answer: The maximum safe DC input voltage for the NI PXIe-2544 is ±8V.



Question: What type of relays does the PXIe-2544 have?



Answer: The PXIe-2544 has FET relays.



Question: What is the maximum insertion loss for the NI PXIe-2544?



Answer: The maximum insertion loss for the NI PXIe-2544 is -6 dB.
