National Instruments 750572-01 DC Power Supply
The National Instruments 750572-01 (Model Name: RMX-4125) is a 1U full-width, single-channel rack-mount DC power supply designed to meet the demands of all types of test and measurement applications. This product provides continuous DC output power up to 1500W and supports DC voltage outputs as high as 80VDC and/or DC current outputs up to 56A, which provide designers with a very large amount of operational range within a small footprint. As a result of its design for integration into automated test systems, the 750572-01 can address applications including but not limited to electronics manufacturing, aerospace, military, automotive testing, semiconductor validation, etc., where precise programmable DC power at a wide voltage-current ratio is required.
This DC Power Supply makes use of a built-in calibration tool so that users may maintain their measurements as traceable and accurate without having to use third-party software. Options available for connectivity on the 750572-01 include USB 2.0, LAN (Ethernet), RS-232, and analog control interfaces; therefore, it has many possible ways it can be used as part of a variety of different test architectures ranging from bench-top configurations to fully automatic rack-based systems. Manual operation via front panel push buttons/rotary knobs is supported by remote operation via LabVIEW, TestStand, and other NI software platforms using standard VISA or IVI driver frameworks.
As a computer-based device, the 750572-01 integrates perfectly into NI's larger test environment and communicates with NI products either via Ethernet or USB without the requirement for a separate chassis or PXI framework. Additionally, due to the ability to set both voltage and current limits independently on the 750572-01, engineers are able to minimize damage to their DUTs while maintaining maximum throughput across various power profiles. With its capability to deliver high output power; communicate via multiple protocols; operate manually and remotely; and have onboard calibration capabilities, NI part number 750572-01 is an ideal solution for applications requiring scalable programmable DC power.
| Model | 750572-01 |
|---|---|
| Part Number | 750572-01 |
| Manufacturer | National Instruments |
| Brand | Emerson |
| Part Type | Single-Channel Rack-Mount DC Power Supply |
| Output Power | 1500 W |
| Voltage output | 0 – 80 VDC |
| Current Output | 0 – 56 A |
| Form Factor | 1U Full-Width 19" Rack |
| Communication Interfaces | USB 2.0, Ethernet, RS-232, Analog |
| Control Methods | Manual (front-panel) / Remote (digital & analog) |
| Host Compatibility | LabVIEW, TestStand, VISA, IVI |
