PCI-8254R

4.8/5 | 18 ratings

Modular Systems > National Instruments > R Series

Part Number PCI-8254R
Manufacturer/Brand National Instruments
Description: PCI-8254R, 29 digital I/O lines, IEEE 1394 Interface
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments PCI-8254R Image Acquisition Board

The NI PCI-8254R (Part number: 779303-01) is an Image Acquisition Board that allows the user to activate and coordinate numerous IEEE 1394 cameras deprived of the needed extra advanced I/O boards or custom hardware. For coordinated vision parts, this model comes with 29 computerized I/O lines. Even though it is not necessary, the client has the option to broaden the usefulness of this instrument by exploiting the reconfigurable I/O innovation. There is a module that can be utilized called NI LabVIEW FPGA. This module allows users to tweak the 29 computerized I/O lines of the module to play out a more extensive assortment of bundling investigation and applications controlled mechanically.

NI-IMAQ has a broad library of capacities users can call and handles communication between the PC and the image securing gadget, such as programming hinders and camera control. NI-IMAQ I/O gives capacities to control the I/O on the NI PCI-8254R which is a customizable device vision programming that can be used to model, benchmark, and send applications. This special configuration is versatile to great programming situations and does not require programming. It enables users to effectively arrange and benchmark a succession of visual assessment ventures and send the visual investigation framework for computerized examination. The user can perform ground-breaking visual investigation errands and settle on choices considering the consequences of individual assignments. The user can also move the designed assessment to LabVIEW. The module included in this model is comprised of NI Vision and NI Vision Assistant and a picture obtaining, preparing, and examination library with over 270 capacities.

ModelPCI-8254R
ManufacturerNational Instruments
Part Number779303-01
TypeIEEE 1394a Interface
Number of Ports2 IEEE 1394a Camera Inputs
Image Data Transfer400 Mb/s
Digital Inputs15 (13 Isolated 24 V lines & 2 TTL lines)
Digital Outputs14 (4 Isolated 24 V & 10 TTL)
Camera InterfaceIEEE 1394a
Power Requirements18 W
Dimensions4.2 in. × 6.9 in.
Weight0.25 lb.
Driver SoftwareNI Vision Acquisition Software
WarrantyOne Year Warranty
PCI-8254R ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
