PXI-8214

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8214
Manufacturer/Brand National Instruments
Description PXI-8214 Ultra2 SCSI Interface Module

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8214 SCSI Interface Module

The National Instruments PXI-8214 is a PXI-to-Ultra2 SCSI Interface Module. This module offers an Ultra2 SCSI interface to CompactPCI (cPCI) or PXI. The PXI-8214 is a single-ended/16-bit low voltage SCI solution that can be used to bond a maximum of 15 SCSI devices with up to 40 MegaTransfer  (MT)/s (80 Mbytes/s) data transfer rates. This model is an ideal solution for PXI/cPCI based systems where true continuous disk operation and true high-speed is required.

The National Instruments PXI-8214 comes equipped with an LSI53C895A PXI-to-Ultra2 SCSI controller. The PXI/cPCI interface incorporated in this model supports up to 133 Mbytes/s bursts at 33 MHz, as well as a 32-bit DMA bus master. The SCSI interface included in this model provisions SE and 16-bit LVD signaling and has a high-density, 68-pin connector. This model comes equipped with an onboard flash ROM for the storage of SCSI BIOS and an SCSI bus activity LED is also provided. With the NI PXI 8214, the user will be able to utilize a 25 m long cable for point-to-point connections.

This module features two connectors P1 and J1. The P1 connector is a cPCI backplane connector, whereas the J1 connector is a 68-contact SCSI device connector. When used in Microsoft Windows XP environment, the NI PXI-8214 installs automatically with the correct driver and the user can ensure its installation through the Device Manager. This interface weighs around 0.13 kg, has physical dimensions of 10.0 by 16.0 cm, and requires one peripheral slot for deployment.

PXI-8214 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.

ModelPXI-8214
ManufacturerNational Instruments
TypeSCSI Interface Module
InterfaceUltra2 PXI SCSI Interface
Data Transfer Rate80 Mbytes/s
Compatibility8- and 16-bit devices
Slot Requirements1 peripheral slot
Dimensions6.3 x 3.9 in.
Weight0.28 lb.
WarrantyOne Year Warranty
PXI-8214 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8214 Frequently Asked Questions



Question: Which SCSI controller is the PXI-8214 based on?



Answer: The PXI-8214 is based on the LSI53C895A SCSI controller.



Question: How many SCSI devices can the NI PXI-8214 connect to at once?



Answer: The NI PXI-8214 can connect to 15 SCSI devices at the most.



Question: What is the maximum cable length for point-to-point connections on the PXI-8214?



Answer: The maximum cable length for point-to-point connections on the PXI-8214 is 25 m.



Question: What type of signaling does the NI PXI-8214 support?



Answer: The NI PXI-8214 supports 16-bit SE and LVD signaling.

PXI-8214 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8214
Type:SCSI Interface Module
Repair Evaluation:$150

Why Buy From Apex Waves

Delivery: UPS, FedEX and DHL – Free UPS Ground on all orders
Overnight, Next Day Air or Expedited shipping options available
International delivery available
Same day shipping for in-stock on location
Warranty: All parts new, new surplus, used or reconditioned are covered by Apex Waves 1 Year Warranty
Returns: No hassle return policy.
Dedicated customer service team.
Payment:
Quick Quotes: Receive Price & Availability Today!
Calibration: Ask About Our Tiered Calibration Levels
Option & Modules: Confirm Your Requirements or Versions
Repair: Cost & Lead Time Available Upon Request for Service
