National Instruments USRP-2901 USRP Software-Defined Radio Device
The USRP-2901 is a USRP Software Defined Radio Device. The NI USRP-2901 is created by National Instruments with part number 784040-01. The USRP-2901 belongs to the series of USRP Software Defined Radio Devices by National Instruments. The NI USRP-2901 device needs a particular application development environment for communication purposes. The ADEs include LabVIEW and the LabVIEW module of Communication System Design. The USRP-2901 device can be connected to the USB 2.0 or USB 3.0 slots. It is recommended to use an external power supply when the NI USRP-2901 connects to the USB 2.0 port.
The National Instruments USRP-2901 USRP Software Defined Radio Device can be operated with an instantaneous bandwidth of 56 MHz for the RF transceiver. The NI USRP-2901 USRP Software Defined Radio Device can function with two channels. The USRP-2901 device is equipped with a radio frequency (RF) transceiver that operates in a full-duplex manner. The frequencies of the NI USRP-2901 USRP Software Defined Radio Device are tunable owing to the desired receivers. The USRP-2901 device can be operated with multiple-input-multiple-output (MIMO) wireless technology.
The NI USRP-2901 USRP Software Defined Radio Device has 70 MHz to 6 GHz RF frequency range. The USRP-2901 device can be applicable for white space, sensor networks, and broadcast FM communication applications. The NI USRP-2901 is also used for low-power unlicensed device bands. The USRP-2901 device can be utilized for land-mobile and public safety purposes. The NI USRP-2901 also works for amateur radio and/or GPS networks. The USRP-2901 device has an ADC resolution of 12-bits.
| Model | USRP-2901 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 784040-01 |
| Type | USRP Software Defined Radio Device |
| Input Channels | 2 |
| Output Channels | 2 |
| RF Frequency Range | 70 MHz to 6 GHz |
| Bus Connector | USB 2.0, USB 3.0 |
| Dimensions | 7.0 in. × 4.9 in. × 1.5 in. |
| Weight | 1.5 lb. |
| USRP-2901 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for USRP-2901:
USRP-2901 PDF Manuals
NI-USRP-29002901-LETTER-OF-VOLATILITY.PDF
USRP-2900-2901-GETTING-STARTED-GUIDE.PDF
USRP-2901-SAFETY-ENVIRONMENTAL-AND-REGULATORY-INFORMATION.PDF
