VXI-1394

4.9/5 | 10 ratings

Modular Systems > National Instruments > VXI and VME

Part Number VXI-1394
Manufacturer/Brand National Instruments
Description: VXI-1394, C-size, IEEE 1394 Remote Controller
In Stock | Ships Today
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments VXI-1394 IEEE 1394 Remote Controller

The VXI-1394 is an IEEE 1394 Remote Controller manufactured by National Instruments. The NI VXI-1394 is built with the part number 183815-01. The VXI-1394 can also be purchased as a kit. The first version (Part Number: 778118-01) is designed for Windows 2000/XP/Me/98. The second version of the kit (Part Number: 778117-01) is made for Windows NT. These kits also come with a 4.5 m FireWire cable, and a PCI-1394 Interface Board. The VXI-1394 is compatible with NI-VXI and NI-VISA driver software, which can be used for troubleshooting and debugging VXI systems and programming libraries. The NI VXI-1394 performs with the recommended software of LabVIEW, LabWindows/CVI, and Measurement Studio.

The NI VXI-1394 links a PCI-based computer to the VXIbus via the IEEE 1394 or FireWire high-speed serial bus. The NI VXI-1394 also has VXI Slot 0 capability, which includes resource manager. The National Instruments VXI-1394 kit enables your computer to perform as if it were plugged into the VXI backplane with the capability of an embedded computer. The VXI-1394 has a maximum throughput of 11 Mbytes/s sustained across the 1394 bus.

The NI VXI-1394 features hot plug-in capability, which means you can add 1394 instruments and configure them without needing to power down your system. Several 1394 instruments can be linked together in a tree topology, although intensifying how complicated the bus topology is can decrease overall system performance. This IEEE 1394 Remote Controller can provide 2-way VXI transfers.

VXI-1394 Obsolete Status has been announced by National Instruments, but the interface will still be available for purchase and repairs by Apex Waves.

ModelVXI-1394
ManufacturerNational Instruments
Part Numbers183815-01, 778118-01, 778117-01
TypeIEEE 1394 Remote Controller
Maximum Throughput11 Mbytes/s
SizeC-size
VXIbus Configuration Space64 B
Slot RequirementsSingle VXI C-size slot
CompatibilityFully compatible with VXI specification
Dimensions9.187 in. × 13.386 in.
Weight2.45 lb. (without DRAM installed)
Warranty2-3 Year Warranty
VXI-1394 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the VXI-1394:

1838.15, 18381.5, 183815-01, 183815-02, 183815B-01, 183815B-02, 183815C-01, 183815C-02, 183815D-01, 183815D-02, 183815F-01, 183815F-02, 183815G-01, 185546A-01, 185607B-01, 185607B-02, 500774A-00, 500796A-00, 777747-01, 777747-02, 777920-01, 778117-01, 778118-01


Associated NSNs for the VXI-1394:

5998-01-513-6162 (5998015136162)
