Tektronix MDO3034 Mixed Domain Oscilloscope
The Tektronix MDO3034 oscilloscope is a 4-channel instrument engineered for integrated domain analysis tasks. The unit supports 350 MHz configuration required in workflows demanding consistent analog accuracy and stable signal fidelity. The system captures waveforms with a 2.5 GSa/s sampling rate that delivers precise temporal resolution. The oscilloscope operates with a 300 V input rating that ensures dependable operation. It integrates a color WVGA display that maintains clear signal visibility during detailed evaluation tasks. The platform includes a six in one architecture that includes advanced functions supporting broad electrical verification design. The MDO3034 combines a spectrum analyzer and arbitrary function generator that enable coordinated stimulus and response characterization. It incorporates a protocol analyzer that supports structured decode functions across multiple serial communication standards.
The unit provides stable decode capability for I2C, SPI, RS232, 422, 485 and UART based signaling systems. The MDO3034 oscilloscope supports embedded functionality through the MDO3EMBD and MDO3COMP options that expand technical workflow coverage. The system provides CAN and FlexRay coverage that facilitates diagnostic assessment across distributed control systems. The device supports aerospace and military protocol analysis with MIL-STD-1553 and ARINC-429 operation under the MDO3AERO module. The platform maintains reliable timing structures that assist compliance verification within regulated environments for repeatable measurements. The mixed domain oscilloscope also supports audio standards including I2S, LJ, RJ and TDM through the MDO3AUDIO configuration. It includes USB, LS, FS and HS capability through the MDO3USB module that broadens peripheral evaluation coverage. The unit uses trigger functions for power limit mask and video signals that strengthen diagnostic processes.
The system includes advanced search tools that accelerate fault identification during sequential domain analysis tasks. The platform maintains signal consistency through matched input characteristics rated at 3.9 pF across all bandwidth variants. The MDO3034 mixed domain oscilloscope supports 200 MHz, 500 MHz and 1 GHz bandwidth options that extend measurement ranges when selecting alternative structures. The standard probing characteristics remain consistent across these variants. The higher bandwidth models provide HS decode capability that supports additional analysis depth during complex waveform evaluations. The Tektronix MDO3034 weighs 4.2 kg which enables stable placement and manageable handling within laboratory setups. The system supports USB connectivity that simplifies documentation workflows and simplifies integration with external computing resources.
| Model | MDO3034 |
|---|---|
| Manufacturer | Tektronix |
| Part Type | Mixed Domain Analog Oscilloscope |
| Number of Channels | 4 |
| Bandwidth | 350 MHz |
| Sampling Rate | 2.5 GSa/s |
| Display Type | Color WVGA |
| Input Voltage | 300 V |
| Weight | 4.2 Kg (9.2 lbs) |
| Interface Type | USB |
