Integrated Power Designs SRW-65-3001 Power Supply
The Integrated Power Designs SRW-65-3001 is a compact, triple output power supply rated to supply 65 watts of output power. This model features a powerful protection mechanism against voltage and overpower. The SRW-65-3001 is a RoHS Compliant power supply that is designed to operate at a universal range of 85-264 VAC Input voltage. The Integrated Power Designs SRW-65-3001 is offered in two variations and can be acquired in either open frame or with chassis/cover. The 4.0” x 6.0” x 1.1” dimensions make the model capable of fitting in 1U applications. This model can also handle 50% to 100% load change, while the recovery time is 2 mS.
The Integrated Power Designs SRW-65-3001 is designed to operate with an economical 1.0% noise at its outputs. This model offers 5.0% cross-regulation at each one of its three outputs. In open frame configuration, the SRW-65-3001 weighs around 0.80 lbs., while it weighs 1.65 lbs. with the chassis and cover. With all outputs at 50% load, the user can achieve ± 1.0%, ± 5.0%, and ± 5.0% centering on the power supply`s first, second, and third output respectively. The hold-up time for this power supply at 120V input and 65W output remains around 16 mS minimum.
This model is a fast loading one, which takes no longer than 1 second for starting up. The Integrated Power Designs SRW-65-3001 takes around 1.5A (true RMS) current, while operating at 85V Input and the peak inrush current for this model is 40 A.
| Model | SRW-65-3001 |
|---|---|
| Manufacturer | Integrated Power designs |
| Series | SRW-65 Series |
| Type | Power Supply |
| Input Voltage | 85~264Vac |
| Outputs | 3 |
| Output Voltages | 5.0 V, 12.0 V, -12.0 V |
| SRW-65-3001 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for SRW-65-3001:
