TDK Lambda GEN20-76 Programmable DC Power Supply
The GEN20-76 Programmable DC Power Supply by TDK Lambda delivers regulated DC output. It uses single-phase input architecture that supports consistent operation across varied installation environments and industrial test platforms. The unit provides precise voltage and current programming within specified limits and operating ranges. It accepts 85 to 265 V AC input voltage without external selection. The input frequency tolerance spans 47 to 63 Hz for dependable power conversion performance under fluctuations.
The wide input capability simplifies deployment across international facilities using different utility standards and infrastructures. The GEN20-76's rated output voltage reaches 20 V DC, while adjustable settings cover the complete range accurately. The output control from 0 to 20 V DC enables detailed characterization procedures during development and validation. The unit gives a rated output current capacity that reaches 76 A for substantial load requirements in advanced electronic systems.
The GEN20-76's adjustable current programming from 0 to 76 A supports controlled testing. The current limiting functionality enhances protection during commissioning and performance verification activities for connected equipment. The power supply delivers 1520 W of output power continuously during specified operation. Power conversion achieves 86% typical efficiency, reducing thermal losses significantly during continuous operation cycles.
The voltage ripple noise is 0.008 Vrms in the range of 5 Hz to 1 MHz. Low ripple makes electronic circuits and precision measurements more accurate. The measured ripple noise is 0.152 Arms within the defined measurement range over the defined frequency limits. The unit is designed for 1U rack mount and tabletop-type installation, which maximizes installation flexibility in limited workspace. It features RS-232 and RS-485 communication interfaces for system connection.
The GEN20-76's built-in communications enable coordinated operation of the broader instrumentation networks and centralized management architectures. It is available in multiple interface options such as LAN, USB, and GPIB for enhanced integration needs.
The LAN functionality is based on the LXI-compliant networked instrumentation environment and distributed control system. The unit is designed to operate from 0 to 50°C depending on the specified conditions for reliable operation. The compliance with CE and UKCA marking requirements supports regulatory alignment across applicable deployment regions.
Part Number |
GEN20-76 |
|---|---|
Manufacturer |
TDK Lambda |
Part Type |
Programmable DC Power Supply |
| Rated Output Voltage | 20 V DC |
| Input Frequency Range | 47 to 63 Hz |
| Rated AC Input Voltage | 85 V to 265 V AC |
| Maximum Output Current | 76 A |
| Input Phase | Single-phase |
| Maximum Output Power | 1520 W |
| Typical Efficiency | 86% |
