TDK Lambda GENH30-25 Programmable DC Power Supply
The GENH30-25 Programmable DC Power Supply delivers regulated power. The unit provides adjustable voltage from 0 V to 30 V at the output side. The single-phase input operation supports environments requiring stable power conversion performance. The architecture combines programmable control functions with consistent electrical parameters for precision tasks. The unit accepts 85 V AC to 265 V AC input voltage for appropriate functioning. The supported frequency range spans from 47 Hz to 63 Hz, ensuring compatibility with standard utility sources. Wide input tolerance maintains dependable functionality during varying mains conditions and operational demands consistently. The rated output voltage reaches 30 V DC while supporting precise programmable adjustment across operating ranges. The current for output extends from 0 A to 25 A, enabling controlled delivery needed for connected apparatus requirements.
The GENH30-25 programmable power supply provides a 750 W rated output power for sustained electrical performance. The unit achieves typical efficiency levels reaching 85% during specified operation. The efficient conversion minimizes unnecessary energy losses while supporting dependable thermal behavior over time periods. Voltage ripple noise measures 0.008 Vrms across the specified 5 Hz to 1 MHz bandwidth range limits. The ripple noise stays at 0.063 Arms during the defined measurement bandwidth for output stability assurance. Low noise levels enable sensitive evaluations under controlled electrical conditions and repeatable results consistently. The built-in RS-232 and RS-485 interfaces offer reliable communication for automated control. The optional LAN LXI-compliant connectivity offers networked instrument management.
The TDK Lambda GENH30-25 is also available in both options, USB and GPIB, to support a wide range of frameworks. Separate analog current control allows external regulation via protected signaling arrangements as needed. The isolated analog control function allows for accurate control with dedicated interface pathways for coordination. The electrical isolation provides improved control integration and separation of command circuits and output safely. The unit is reliable between ambient temperatures of 0 °C and 50 °C. The unit also has thermal design features that facilitate stable operation when operating under prescribed situations continuously. Operating specifications allow the planning of equipment racks, benches, and technical work spaces. It is available in a 1U rack mount and a tabletop.
