TDK Lambda HWS600-48 Single Output Industrial Power Supply
The TDK Lambda HWS600-48 is a single-output industrial power supply. It converts AC or DC input power into a regulated 48 VDC output. This unit supplies up to 624 W of continuous output power for industrial loads. The model is built for automation and control system applications.
The HWS600-48 switches at an operating frequency of 190 kHz. Its temperature coefficient is specified at 0.02 percent per degree Celsius. The unit operates without requiring any minimum connected load. The power supply accepts a single-phase AC input from 85 to 265 Vac. It also accepts a DC input ranging between 120 and 330 VDC. This wide input range supports operation across regional power systems. The model maintains stable output under varying line voltage conditions. The power supply supports an external load capacitance of up to 5000 uF.
The rated output voltage of the industrial power supply is 48 Vdc. Its output voltage range extends from 38.4 to 52.8 Vdc. The maximum continuous output current from this unit is 13 A. The HWS600-48 reaches a typical efficiency of 86 percent at rated load. The overcurrent protection on the power supply activates above 105 percent of rated current. The overvoltage protection causes the unit to latch and shut down. Cycling the AC input restores the model after an overvoltage fault.
A green LED on the front panel indicates normal DC output status. The HWS600-48 single-output industrial power supply operates across an ambient temperature range of negative 10 to 70 degrees Celsius. The output power derates linearly to 50 percent load between 50 and 70 degrees. The cooling for the power supply is provided through an internal fan. The isolation resistance exceeds 100 megohms measured at 25 degrees Celsius and 70 percent relative humidity.
The withstand voltage from input to output is rated at 3000 Vac for one minute. The model weighs approximately 1600 grams with dimensions of 100 by 82 by 165 mm. The connections to the unit are made through screw terminals. The HWS600-48 withstands vibration up to 19.6 meters per second squared when non-operating.
| Model | HWS600-48 |
|---|---|
| Manufacturer | TDK Lambda |
| Part Type | Single-Output Industrial Power Supply |
| Maximum Output Current | 13 A |
| Input Voltage Range: DC | 120 to 330 VDC |
| Rated Output Voltage DC | 48 VDC |
| Efficiency | 86% Typical |
| Output Voltage Range: DC | 38.4 to 52.8 VDC |
| Input Type | Single-Phase |
| Input Voltage Range: AC | 85 to 265 Vac |
