Anritsu 69347A Signal Generator
The 69347A is the microprocessor-based synthesized Signal Generator by Anritsu. This model has a wide range of measurement capabilities. The Signal Generator has a compact size and shape, which can be utilized for numerous bench top applications. The 69347A Signal Generator offers a frequency range of 10 MHz to 20 GHz. The instrument also offers various modulation schemes to the users. It includes AM, FM, phase, and pulse modulation schemes. These modulation schemes are implemented through internal or external means.
The Anritsu 69347A Signal Generator offers very low noise. It is for test signals at the output. It helps the user to achieve accurate measurements. The device also incorporates the AM scan capability. It is optional as per requirement of the user. The user can also include internal power meter as an option. The device comes with a built-in LCD on the front panel, which presents the various status parameters of the instrument. The user can also control setup menus of the 69347A through the LCD. The function keys are integrated on the front panel and further simplifies the operation of the instrument. The user can enable the security mode and self-test diagnostics from here.
The 69347A Signal Generator offers a high output power with amazing signal frequency stability. It combines state of the art technologies to deliver high-performance standards. The instrument also offers a fast switching time, which helps to maximize the throughput of the system. The 69347A Signal Generator provides the optional capability for SCPI programming.
| Model | 69347A |
|---|---|
| Manufacturer | Anritsu (Anritsu Kabushiki-gaisha) |
| Series | 693XXA Series |
| Type | Signal Generator |
| Frequency Range | 10 MHz to 20 GHz |
| Output Power | +13 dBm |
| Mass | 50 lb. |
| Dimensions | 5.25 x 16.875 x 23.5 in. |
| 69347A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
