LitePoint z3975 PXI Embedded Controller
The LitePoint z3975 PXI embedded controller supports advanced modular testing workflows with a focused technical architecture. This controller uses an Intel Core i5 520E processor running at 2.4 GHz to maintain reliable processing performance under structured measurement loads. It operates with dual channel DDR3 SODIMM memory rated at 4 GB and 1066 MHz to ensure dependable data handling. The z3975 PXI embedded controller provides stable operation during precision oriented system activities. The unit supports a maximum throughput of 2 GB per second for controlled processing tasks during active instrumentation. The two PXI Express links configured as x8 and x8 extend the platform bandwidth for integrated system level coordination. The z3975 controller uses integrated SATA storage with defined drive options that support structured data management. The system may be configured with a 320 GB HDD or a 160 GB SSD depending on operational demands.
The dual Gigabit Ethernet ports support stable network connectivity for instrument control and data transfer operations. Four USB 2.0 ports are present to support external device interaction inside controlled PXI environments. A built in GPIB IEEE 488 controller enables legacy instrument communication for specialized measurement setups. The z3975 module uses DVI I video connector that supports direct display integration to allow reliable system configuration and visual status monitoring. An ExpressCard 34 expansion slot provides additional flexibility for hardware required by specific test environments. This PXI controller includes trigger input and output resources that support coordinated PXI function timing. A programmable watchdog timer is implemented to maintain controlled system recovery when defined conditions occur during operation. The controller runs Windows 7 x32 which supports compatibility with established measurement frameworks and automated test procedures.
The power requirements include 0.12 A at 5 V during standby operation under low energy demand conditions for the z3975 PXI controller. The typical functional operation requires 0.75 A at 3.3 V and 0.76 A at 5 V during active tasks. The design occupies 1 system slot and 2 expansion slots which supports structured modular placement within PXI chassis systems. The LitePoint z3975 PXI embedded controller weighs just 0.9 kg (1.98 lbs) which promotes stable mounting inside multi slot chassis frames. The system operates from 0°C to 50°C and stores safely from -20°C to +70°C while supporting 5% to 95% humidity.
| Model | LitePoint z3975 |
|---|---|
| Manufacturer | LitePoint |
| Part Type | PXI Embedded Controller |
| Processor | Intel Core i5-520E 2.4 GHz |
| Memory | 4 GB DDR3 SODIMM 1066 MHz |
| Maximum Throughput | 2 GB/s |
| Storage Options | 320 GB HDD or 160 GB SSD |
| Ethernet Ports | Dual Gigabit Ethernet |
| Video Output | DVI-I connector |
| Operating Temperature | 0°C to +50°C |
