National Instruments 778733-01 Terminal Block
The National Instruments part number 778733-01 (Model Name TB-2630) is designed to be a PXI terminal block that allows you to directly attach it to your PXI-2530 matrix switch module. It has a 2x9" footprint with a .100" spacing and includes 8 ribbon cable headers. The terminal block attaches to the front of the PXI-2530 via two chassis screws on each side, ensuring a solid and secure connection of the signal wires from the terminal block to the chassis, ultimately allowing you to route signals reliably inside of a PXI chassis. The terminal block also has screw terminals for your trigger inputs and outputs so that you can easily connect these signals when synchronizing your measurements or controlling other devices in your setup.
The National Instruments 778733-01 is designed to allow you to use the PXI-2530 Matrix Switch as a multiplexer, which will help you to efficiently route your signals when building automated test systems, data acquisition systems, or industrial control systems. If you need to set up multiple matrix configurations, National Instruments also supplies terminal blocks like the TB-2631 and TB-2632; however, they are used for matrix configurations, whereas the 778733-01 is used for multiplexer configurations. The device has a number of ways to connect into your system, including 8 ribbon cable headers and two screw terminals for connecting your triggers into your system. These connectors allow you to create a high-density bus for your data connections and a separate line for your triggers, all contained in one small package.
The 778733-01 is an essential tool for enhancing the signal routing capability of the PXI-2530 in demanding engineering environments. Installing this product is easy; the cable type is standard, and the product securely connects into place mechanically, making the terminal block a simple solution for laboratory automation, production testing, and research applications where high-density reliable switching is needed. The NI 778733-01 clearly defines the physical interfaces for both data and trigger signals, allowing engineers to keep their wiring schemes organized and maintainable while using the full multiplexing functionality of the PXI-2530 Matrix Switch Module.
| Model | 778733-01 |
|---|---|
| Model Name | TB-2630 |
| Part Type | PXI Terminal Block |
| Compatible Module | PXI-2530 |
| Connection Type | Ribbon headers and screw terminals |
| Ribbon Connector Pitch | 0.100 in (2×9) |
| Compatible Cable Pitch | 0.050 in |
| Number of Connectors | Eight |
| Trigger Interface | Screw terminals for I/O triggers |
| Matrix-Mode Blocks | TB-2631, TB-2632 |
