National Instruments TB-2630 PXI Terminal Block
The National Instruments TB-2630 (Part Number: 778733-01) is a PXI Terminal Block made to be used with the PXI-2530 Matrix Switch Module. The TB-2630 terminal block can be easily installed onto the front of the PXI-2350, allowing for exanded signal routing capabilities. With ribbon cable headers and screw terminals for trigger input and output signals, the TB-2630 offers a versatile solution for efficient and reliable signal transmission.
To connect the TB-2630 terminal block, first verify that the NI PXI-2530 is securely installed in a PXI chassis. Then, insert the TB-2630 into the front connector of the PXI-2530. To ensure that the terminal block is secure, the top and bottom chassis screws located on the rear of the panel should be tightened.
The TB-2630 is equipped with eight pitch ribbon cable connectors that measure 2 × 9 inches and 0.100 inches. allowing for effortless connectivity in a variety of assemblies. Any 0.050 in. pitch ribbon cable is compatible with the TB-2630, providing added flexibility to your setup.Double row ribbon cable connectors use a pitch that is half of the connector's. For example, if you have a 0.100 in. pitch connector then you'll need 0.050 in. ribbon cables for it to work properly.The pitch of the connector typically defines ribbon cable connector assemblies. In certain cases where a ribbon cable with more than 18 conductors is required, the unwanted conductors can be removed prior to use.
The PXI-2530 switch module provides an extensive array of multiplexer and matrix configurations for any purpose. It is important to determine the right terminal block for your required configuration when using the TB-2630, which specifically configures the switch as a multiplexer. The National Instruments Terminal Blocks TB-2631 and TB-2632 are dedicated to matrix configurations for the PXI-2530.
| Model Name | TB-2630 |
|---|---|
| Part Number | 778733-01 |
| Part Type | PXI Terminal Block |
| Compatible With | The NI PXI-2530 |
| Dimensions | 3.3 in x 4.1 in |
| Warranty | Three Year Warranty |
| TB-2630 Manuals | PDFs Available for Download |
