TB-2634
Test & Measurement Misc > National Instruments > Terminal Blocks
| Description: | TB-2634, 2-wire, 4 x 32 matrix, Terminal Block |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
NI TB-2634 Terminal Block
The TB-2634 is a Terminal Block that is designed for the PXI-2529. This 2-wire Terminal Block is deployed on the front of the switch module. The TB-2634 comes with ribbon cable headers that offer direct access to the columns and the rows of the matrix. Moreover, it contains connections for the trigger output and the trigger input signals. The part number of this Terminal Block is 778840-01.
The NI TB-2634 is rated for Category I measurements only and intended to carry up to 150 V signal voltages. However, it can withstand surge voltages up to 800 V. A system containing this Terminal Block usually includes a PXI Chassis installed with the PXI Switch Module. The front connector of the PXI-2529 can easily be mated to the connector found on the TB-2634 Terminal Block. Through this accessory, you will be able to configure your switch module as a 2-wire, 4 x 32 matrix.
| Model | TB-2634 |
|---|---|
| Manufacturer | NI |
| Part Number | 778840-01 |
| Type | Terminal Block |
| Compatible Models | NI-2529 |
| Configuration | 2-wire, 4 x 32 matrix |
| Maximum Current | 1.5 A |
| Warranty | 2-3 Year Warranty |
| TB-2634 Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
Associated part numbers for the TB-2634:
190086A-01, 190086B-01L, 190086C-01L, 190086D-01L, 778840-01
Associated NSNs for the TB-2634:
5940-01-664-6694 (5940016646694), 5998016081801, 5998-01-608-1801 (5998016081801)
