Part Number PCI-6713
Manufacturer/Brand National Instruments
Description: PCI-6713, 8-Channel, 12-Bit, Analog Output Device
In Stock | Ships Today
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments PCI-6713 Analog Output Device

Featured with 8 Analog Output Channels, 2 Counters, and 8 Digital Input/Output Channels, the National Instruments PCI-6713 (Part Number: 777741-01) is a PCI based multifunction analog output, timing input/output, and DIO device. This device is designed to operate as a plug and play unit entirely. For each of its 8 analog output channels, a dedicated 12-bits digital-to-analog converter is provided that offers up to 1 MS per second update rates for voltage outputs. This model also has eight 5 V TTL/CMOS compatible digital input/output lines. It has 3 DMA channels with a scather-gather DMA mode, a 5V PCI master-slave bus interface.

The counter/timers incorporated in this device are 2 in number, have 24-bit resolution, and have a frequency of 20 MHz, 100 kHz. It has 1 frequency scaler with base clocks of 10 MHz, 100 kHz. The device has a maximum working voltage of ±11 V, CAT 1 for a channel-to-earth isolation; and ±22 V, CAT 1 for a channel-to-channel. The PCI 6713 National Instruments supports hardware-based digital triggering as well. This model comes equipped with DAQ-STC which makes possible selectable logic level, PFI lines, and frequency shift keying. Moreover, the DAQ-STC also brings a variety of buffered operations, such as up/down control, equivalent time sampling, single pulse generation, pulse train generation, buffered period, and semi-period measurements. The NI device is equipped with a 68-pin male SCSI-II I/O connector.

The PCI 6713 Analog Output Device consumes 1.25 amperes at +5 VDC (±5%), whereas it offers +4.65 VDC to +5.25 VDC power at the I/O connector (at 1 A). In addition to redundant counters/timers, 4-bit, 10 MHz, 100 kHz frequency scalers are also incorporated in this module. This device is capable of identifying, measuring, and correcting for any of its calibration related errors. The software program provided with the NI PCI-6713 device defines a self-calibration method. The self-calibration process takes less than two minutes in most cases. To ensure the integrity of self-calibration, this device comes with an onboard calibration reference as well. The device measures 6.87 x 4.2 in. in physical dimensions. It has a recommended operating temperature range of 0 to 50 °C.

ModelPCI-6713
ManufacturerNational Instruments
Part Number777741-01
TypeAnalog Output Device
Analog Output Channels8 (12-Bit, 1 MS/s)
Digital Inputs/Outputs8 (5 V TTL/CMOS Compatibility)
Timing I/O2 Counter/Timer I/O (24 bits, 20 MHz)
I/O Connector68-pin male SCSI-II
Power Requirements+5 V -- 1.25 A
Dimensions6.87 × 4.2 in.
Software DriverNI-DAQmx
Measurement & Automation Explorer configuration utility
WarrantyThree Year Warranty
PCI-6713 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the PCI-6713:

18503, 185030-01, 185030A-01, 185030B-01, 185030C-01, 185030D-01, 185030F-01, 185030G-01, 185030H-01, 185030J-01, 185030K-01L, 777741-01


Associated NSNs for the PCI-6713:

5998-01-678-1732 (5998016781732)

National Instruments PCI-6713 Frequently Asked Questions



Question: Will my PCI 6713 National Instruments fit in a PCI-X slot on a computer?



Answer: The PCI 6713 National Instruments may be compatible with a PCI-X slot; it is based on the keying in the card. Universal PCI standard keying is compatible.



Question: What is the PCI 6713 driver software?



Answer: The PCI 6713 driver software is NI-DAQmx.



Question: What is the update rate of the NI PCI-6713?



Answer: The update rate of the NI PCI-6713 is 740 k to 1 M (S/s) for each channel.



Question: Which type of compatibility do the digital I/O channels on the PCI-6713 have?



Answer: The digital I/O channels on the PCI-6713 are TTL/CMOS compatible.
