PCI-6520

Modular Systems > National Instruments > DIO Series

Part Number PCI-6520
Manufacturer/Brand National Instruments
Description PCI-6520 16-Channel, 8 Sink/Source Inputs, 8 Relay Outputs, Digital I/O Device
In Stock | Ships 2-4 Weeks

Speak to a sales representative for pricing & lead time:


National Instruments PCI-6520 Digital I/O Device

The PCI-6520 (Part Number: 779443-01) has a locally available time-base for any information securing gadget that goes about as the inner pulse that drives all advanced hardware. The NI PCI-6520 offers 16 channels, ±30 VDC, 8 Sink/Source Inputs, 8 Relay Outputs (60 V), and is an Isolated Digital I/O Device.

Everything from test tickers to trigger lines utilizes the time-base as a locally available reference to create clock frequencies and hook advanced edges. Current gadgets utilize a 100 MHz time-base for all simple and computerized timing, which is up to five times speedier than their antecedents. This implies testing frequencies are up to five times more exact and simple triggers can react inside 10 ns of a trigger condition being met.

By wiping out the confinements of equipment parts generally utilized for gadget blunder rectification and utilizing the power and speed of programming and PC preparing, NI-MCal increases current standards for estimation exactness by rethinking gadget self-adjustment. Most Multifunction I/O Device models have a two-year outer adjustment cycle because of the self-alignment exactness hardware that limits the upkeep weight of conveyed frameworks, while likewise keeping up tight estimation resilience.

In applications that drive some high-current loads, a lot of current must be returned on the GND pins. While associating the NI PCI 6520 to different loads, physically interface with all GND sticks on the gadget. Interfacing with all GND pins appropriates the current equally among the GND sticks and brings down the measure of current driven on any single link wire and on the adornment terminals.

ModelPCI-6520
ManufacturerNational Instruments
Part Number779443-01
TypeDigital I/O Module
Input Lines8 Source/Sink
Output Lines8 Electromechanical Relays
Maximum Input Voltage±30 VDC
Maximum Input Current12.5 mA/line
Propagation Delay45 μs
I/O Connector37-pin male D-SUB
Power Requirements+5 VDC - 600 mA
Dimensions6.9 in. × 3.9 in
Weight0.33 lb.
Driver SoftwareNI-DAQmx
WarrantyOne Year Warranty
PCI-6520 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-6520 Frequently Asked Questions



Question: What is the digital input voltage range of the PCI 6520?



Answer: The digital input voltage range of the PCI 6520 is -30 V to 30 V.



Question: What is the NI PCI-6520 driver software?



Answer: The NI PCI-6520 driver software is version 7.5 or higher of NI-DAQmx.



Question: Which type of isolation does the NI PCI 6520 Digital I/O Device have?



Answer: The NI PCI 6520 Digital I/O Device has channel-to-channel isolation.



Question: What is the default power-on and power-off states of the electromechanical relay outputs on the PCI-6520?



Answer: The default power-on state of the electromechanical relay outputs on the PCI-6520 is de-energized; user-programmable to de-energized or energized. The default power-off state is relays de-energized.

PCI-6520 Technical Specifications:


Manufacturer:National Instruments
Model:PCI-6520
Part Number:779443-01
Type:Digital I/O Device
Repair Evaluation:$150
