National Instruments FP-DI-330 Digital Input Module
The NI FP-DI-330 (Part Number: 777518-330) module faculties an extensive variety of AC signals. The base ON-state voltage for an AC signal relies upon the frequency of the flag. When an outside gadget applies a voltage between 1 V and the base ON-state voltage over the input terminals, the channel might enroll an ON condition. This fitting and play activity disentangles framework establishment, arrangement, and upkeep. FieldPoint frameworks incorporate an OPC Server complimentary. In this way, the user can simply coordinate FieldPoint frameworks with any product that has OPC customer capacity. OPC is an industry standard interface dependent on ActiveX and OLE innovation. Since OPC utilizes DCOM innovation, customer applications can get to information from remote OPC servers over the system. With the SnapShot included, the user can easily set the default control up states and arrangements of their I/O modules. After intelligently designing the I/O modules to the wanted settings (setup as well as yield esteems), the user can issue the SnapShot order. This model also offers a multi-window interface that guides the user through all parts of fieldbus and FieldPoint setup, including gadget arrangement, work square design, and venture and timetable administration.
National Instruments guarantees that the gadgets associated with the FP-DI-330 have OFF-state spillage flows lower than 350 µA. Higher spillage flows can cause false ON readings. The FP-DI-330 uses eight optically segregated information channels, so each computerized info has a different ground plane. The user can utilize each channel with an alternate voltage potential.
| Model | FP-DI-330 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777518-330 |
| Type | Digital Input Module |
| Digital Input Channels | 8 |
| Channel-to-ground Isolation | 250 Vrms, Installation Category II |
| Input Delay Time | 1.2 ms |
| Power from Network Module | 200 mW |
| Weight | 4.5 oz. |
| FP-DI-330 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for FP-DI-330:
National Instruments FP-DI-330 Frequently Asked Questions
Question: What is the input channel compatibility for the NI FP-DI-330?
Answer: The input channel compatibility for the NI FP-DI-330 is TTL, CMOS, 24 VDC, 48 VDC, 120/240 VAC.
Question: What is the maximum input voltage for the FP-DI-330 module?
Answer: The maximum input voltage for the FP-DI-330 module is 250 VAC or 250 VDC.
Question: How can I link a sourcing-output instrument to the NI FP-DI-330?
Answer: To link a sourcing-output instrument to the NI FP-DI-330, the user can link a power supply to the V and C terminals of the FP-DI-330. Then, link the Vsup, INa, INb, and COM terminals to the sourcing-output instrument.
Question: How many status LEDs does the FP-DI-330 module have?
Answer: The FP-DI-330 has two green status LEDs, POWER and READY.
