National Instruments NI-5771 Digitizer Adapter Module for FlexRIO

The National Instruments NI-5771 (Part Number: 781419-02) is a 2-Channel, 900 MHz Bandwidth, 8-Bit, Digitizer Adapter Module that is designed for FlexRIO based systems specifically. This device can sample one channel at 3.0 GS/s or two channels at 1.5 GS/s. This model can operate over an analog input voltage range of -0.675 V to 0.675 V and is compatible with Virtex-5 and Kintex-7 FPGAs. The NI-5771 comes with 2 SMA type analog input connectors (AI 0 and A1), which support DC input coupling.

This device comes with a 1.5 GHz, VCXO type onboard internal sample clock. The NI-5771 has a CLK IN connector and a CLK OUT connector. The AUX I/O connector is an HDMI connector. This module contains 12, bi-directional channels (4 PFI and 8 DIO) and supports 3.3 V LVCMOS interface standard. In addition, the National Instruments NI-5771 Digitizer Adapter Module for FlexRIO features a single-ended, SMB type TRIG connector. It is important to note that users can utilize a third-party, standard, HDMI cable with the AUX I/O connector. However, the AUX I/O port offered in this device is not an HDMI interface.

Users can utilize any 50 Ω coaxial, shielded cable to connect to the connectors provided on the NI 5771 front panel.  This module weighs around 413 g and has dimensions of 12.9 × 2.0 × 12.1 cm. The module supports software which includes a broad range of example projects to assist users in creating their LabVIEW FPGA application.

ModelNI-5771
ManufacturerNational Instruments
Part Number781419-02
TypeDigitizer Adapter Module for FlexRIO
Voltage Input Channels2
Maximum Sample Rate3 GS/s
Analog Input Resolution8 bits
Dimensions5.1 x 0.8 x 4.7 in.
Weight14.6 oz.
WarrantyOne Year Warranty
NI-5771 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5771 Frequently Asked Questions



Question: What is the analog input voltage range of the NI-5771?



Answer: The analog input voltage range of the NI-5771 is -0.675 V to 0.675 V.



Question: What does NI 5771R refer to? Is it the same as the NI 5771?



Answer: The NI 5771R is the name for the NI 5771 combined with the NI FlexRIO FPGA module.



Question: What is the part number for the ADC on the NI-5771?



Answer: The part number for the ADC on the NI-5771 is ADC08D1520.



Question: How many front panel connectors are on the NI 5771?



Answer: The NI 5771 has seven total front panel connectors: five SMA, one SMB, and one HDMI.
