National Instruments NI-6589 Digital I/O Adapter Module for FlexRIO

The NI-6589 (Part number: 783888-01) Digital I/O Adapter Module from National Instruments has the following features: a maximum data rate of 1 Gbit/s, 20 bidirectional digital channels, differential signaling, a maximum clock rate of 1 GHz, 100 Ohm digital I/O termination, and compatibility with a Kintex-7 FPGA. This LVDS Digital I/O Adapter Module can carry out the interfacing standard protocols and implementing customized protocols at various voltage levels. When combined with PXI FPGA Modules or Controllers for FlexRIO, this Digital I/O Adapter Module becomes an instrument capable of interfacing with 20 low voltage differential signaling digital pins. The NI 6589 is designed to support common LVDS voltages and sample waveforms up to 1 GHz.

The NI 6589 Digital I/O Adapter Module for FlexRIO can address a range of requirements, including the real time emulation of custom protocols and high speed communication with a device under test. FlexRIO systems are designed for engineers whose requirements include the flexibility of customized hardware without the cost of customized design. The NI-6589 Digital I/O Adapter Module for FlexRIO can be fully reconfigured and programmed graphically with LabVIEW or VHDL/Verilog. Target applications for FlexRIO include RADAR, communications, medical imaging, automated test, signals intelligence, communications, and scientific and medical instrumentation.

FlexRIO’s architecture offers the advantage of using the most advanced high-speed technologies prior to when they are generally available in conventional commercial-off-the-shelf instruments, which is useful in applications that continuously require a higher sample rate, resolution, bandwidth, and channel count.

ModelNI-6589
ManufacturerNational Instruments
Part Number783888-01
TypeDigital I/O Adapter Module for FlexRIO
Bidirectional Digital Channels20
Maximum Clock Rate1 GHz
Maximum Data Rate1 Gbits/s
Dimensions5.1 x 0.8 x 4.9 in.
Weight10.6 oz.
WarrantyOne Year Warranty
NI-6589 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-6589 Frequently Asked Questions



Question: Which accessories are required for the NI 6589?



Answer: The NI 6589 requires an FPGA module (the PXIe-7971R, PXIe-7972R, PXIe-7976R, or PXIe-7975R), the SMA-2164 LVDS Connector Block, an I/O Cable (the SHB12X-B12X Shielded Cable or SHB12X-H3X24 Differential Flying-Lead/LA Cable for HSDIO), and an SMA Connector (the SMA Male to SMA Male Cable, 50 Ohm, 30 cm or 1 m).



Question: Which type of signaling does the NI-6589 support?



Answer: The NI-6589 supports differential signaling.



Question: Why does the NI 6589 have to be used with shielded cables and shielded accessories?



Answer: The NI 6589 has to be used with shielded cables and shielded accessories to comply with the EMC standards.



Question: Which types of front panel connectors are on the NI-6589?



Answer: The NI-6589 has one 73-pin InfiniBand connector and two SMA connectors on the front panel.
