National Instruments 780575-01 PCIe-GPIB Instrument Control Interface
The National Instruments 780575-01 (PCIe-GPIB) is a low-profile IEEE 488 controller card engineered to add standard GPIB instrument control capabilities to PCI Express-enabled computers. Designed to maximize IEEE 488.2 transfer speeds up to 7,980 kB/s, the card features an onboard Bus-Master DMA controller that offloads data transfers directly from the system CPU. This architecture minimizes microprocessor overhead, ensuring efficient, high-throughput communication between the host computer and connected hardware.
Equipped with a standard 24-pin female GPIB connector, the 780575-01 acts as a central communication link between desktop PCs or rack-mounted workstations and a wide array of GPIB-enabled instruments, including digital multimeters, oscilloscopes, signal generators, and spectrum analyzers. The low-profile form factor enables seamless installation in space-constrained or small-form-factor chassis, while a 0°C to +55°C operating temperature range ensures dependable performance in both laboratory and industrial settings.
Fully supported by NI-488.2 driver software for Windows (with additional support for Linux and macOS), the module offers broad cross-platform compatibility and simplifies software development for multi-vendor instrument setups. Although it does not include an onboard hardware protocol analyzer, its combination of PCI Express bus speed, dedicated DMA processing, and reliable driver support makes the 780575-01 an ideal choice for automated test equipment (ATE), laboratory automation, and high-speed data acquisition systems.
| Model | 780575-01 |
|---|---|
| Part Number | 780575-01 |
| Part Type | GPIB PCIe Controller |
| Host Bus | PCI Express |
| Max Transfer Rate | 7980 kB/s |
| Form Factor | Low-profile |
| GPIB Ports | 1 (IEEE 488) |
| DMA Support | Bus-mastering onboard |
| Built-in Analyzer | No |
| OS Support | Windows |
