National Instruments 787987-00 PXIe-8862 2.6 GHz 8-Core PXI Express Embedded Controller
The National Instruments 787987-00 (PXIe-8862) is a high-performance 3U PXI Express embedded controller designed for computationally demanding automated test, data acquisition, and hardware-in-the-loop (HIL) simulation applications. Powered by an 11th Gen Intel Core i7-11850HE 8-core processor operating at a 2.6 GHz base frequency with 24 MB of Intel Smart Cache, the module delivers exceptional multi-threaded performance. Supported by Gen 3 PCI Express link speeds up to 8.0 GT/s across the backplane, the controller achieves a maximum controller bandwidth of 16 GB/s. Memory comes standard with 16 GB of dual-channel DDR4-3200 SODIMM RAM (2 × 8 GB), expandable up to 32 GB (2 × 16 GB), while primary storage is provided by an onboard non-removable 512 GB NVMe SSD running under a 64-bit Windows 10 operating system (with support for Windows 11 IoT and NI Linux Real-Time).
To support broad instrument interfacing and multi-monitor test benches, the 787987-00 includes an optional IEEE 488 (GPIB) interface alongside a complete suite of modern front-panel connections. Video outputs feature dual DisplayPort 1.4 connectors, while peripheral interfaces offer two SuperSpeed USB 3.0 Type-A ports and a front-accessible SMB connector for direct PXI trigger bus input/output synchronization. High-speed network communications and deterministic synchronization are driven by dual Intel i225 2.5 GbE Ethernet ports (supporting 10/100/1000/2500Base-T speeds) integrated with IEEE 1588 Precision Time Protocol (PTP) hardware timing.
Occupying a 4-slot 3U PXI Express module footprint (requiring one system slot plus three controller expansion slots), the unit weighs approximately 783 g (1.73 lb) for compact integration into space-constrained test racks. Electrical specs indicate a typical current draw of 1.4 A at +3.3 V and 7.1 A typical (8.5 A maximum) at +12 V drawn directly from the chassis backplane. Built for rigorous industrial operations, the module operates reliably across ambient temperatures ranging from 0 °C to 55 °C (-40 °C to 71 °C storage) and non-condensing relative humidity tolerances from 10% to 90% (5% to 95% storage).
Part Number |
787987-00 |
|---|---|
Model Name |
PXIe-8862 |
Part Type |
PXIe, 2.6 GHz, 8-Core Processor PXI Controller |
Optional GPIB |
Yes |
Hard Drive Memory Size |
512 GB |
Number Of Cores |
8 |
Controller OS |
Windows 10 64-bit |
HDD Removable |
No |
Maximum Controller Bandwidth |
16 GB/s |
Processor Core |
Intel Core i7 |
