National Instruments 780587-24 PXIe-2524 Multiplexer Switch Module
The National Instruments 780587-24 (PXIe-2524) is a high-density, 128-channel PXI Express multiplexer module designed for precise signal routing in high-speed automated test systems. Capable of handling up to 150 VDC and 2 A per channel with a 10 MHz bandwidth, the unit features long-life electromechanical relays that support scan rates up to 1,000 cycles per second. The module offers versatile hardware configurability, supporting five distinct 1-wire multiplexer topologies: single 128x1, dual 64x1, quad 32x1, octal 16x1, and 16-bank 8x1. This flexibility allows engineers to tailor the channel count and bank layout to specific application requirements within a single PXI Express slot.
To maximize system uptime and operational reliability, the 780587-24 includes onboard relay cycle counting, enabling predictive maintenance tracking before hardware failures occur. The high-speed PXI Express interface guarantees rapid command execution and synchronization with adjacent instrumentation. Built for space-efficient, high-density switching, the module easily routes signals from dozens of sensors or devices under test (DUTs) to a centralized measurement instrument, significantly reducing system footprint and test cycle times.
Engineers across aerospace, automotive electronics, and semiconductor validation rely on the PXIe-2524 for data acquisition, high-channel-count signal scanning, and functional test stations. Its 150 V / 2 A rating easily accommodates a wide variety of industrial sensors, loads, and actuators. Fully integrated with NI-SWITCH driver software and NI Switch Executive, the 780587-24 provides an easily programmable interface for automating complex switching sequences in high-throughput production and validation environments.
| Model | 780587-24 |
|---|---|
| Part Number | 780587-24 |
| Part Type | PXI Multiplexer |
| Bus Connector | PXI Express |
| Scan Rate | 1000 cycles/s |
| Switching Mode | 1-wire |
| Max DC Current | 2 A |
| Max DC Voltage | 150 V |
| Bandwidth | 10 MHz |
| Max Channels | 128 |
