National Instruments PXIe5650 PXI RF Analog Signal Generator

The PXIe-5650 (Part Number: 781215-01) is an RF Analog Signal Generator with these features:

·         Frequency Range from 500 kHz to 6.6 GHz

·         Frequency resolution of 2 Hz

·         <2 ms Frequency Sweep Tuning Speed Typical

·         <1 ppb Frequency Resolution

·         FM, 2-FSK, OOK Modulation

The National Instrument PXIe-5650 offers the functionality of RF Signal Generators in a modular, compact PXI form factor. The NI PXIe-5650 can be combined with other PXI modules to design automated test systems for radar, RF integrated circuits (RFICs), and automotive test applications. The NI PXIe5650 PXI RF Analog Signal Generator features continuous-wave generation capabilities with FM, 2‑FSK, or OOK modulation. This model also has a frequency resolution <3 Hz.

This PXI RF Analog Signal Generator is ideal for clocking nonstandard sample rates, such as WCDMA signals at baseband or intermediate frequency (IF). The PXIe 5650 is adaptable and flexible and can be used to perform analog and digital modulation through the onboard DDS circuit.

The NI PXIe 5650 RF Analog Signal Generator has a maximum internal clock accuracy of ±1 ppm when the temperature is between 15 ºC to 35 ºC. This model has an internal reference output frequency up to 10 MHz, an output impedance of 50 Ω, and an amplitude of 1 Vpk-pk into 50 Ω. The PXIe 5650 RF Analog Signal Generator’s dimensions are 0.8 in. × 5.1 in. × 8.5 in. This model weighs 14.6 oz.

ModelPXIe-5650
Part Number781215-01
ManufacturerNational Instruments
TypePXI RF Analog Signal Generator
Module Width1
Maximum Output Power12 dBm
Frequency Range500 kHz to 1.3 GHz
Dimensions8.5 x 0.8 x 5.1 in.
Weight14.6 oz.
WarrantyOne Year Warranty
PXIe-5650 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXIe-5650 Frequently Asked Questions



Question: What is the typical analyzer tuning time for the PXIe-5650?



Answer: The typical analyzer tuning time is 1.5 ms for the PXIe-5650.



Question: What is the NI PXIe-5650 driver?



Answer: The NI PXIe-5650 driver is NI-RFSG.



Question: What is the purpose of the RF OUT connector on the PXIe-5650?



Answer: The RF OUT connector on the PXIe-5650 is an output terminal for the RF signal at the specified frequency and power level.



Question: What is the resolution of the NI PXIe-5650?



Answer: The resolution of the NI PXIe-5650 is <3 Hz.
