National Instruments PXI-7854R PXI Multifunction Reconfigurable I/O Module

The PXI-7854R (Part number: 780342-01) is part of the R Series of Reconfigurable I/O (RIO) devices by National Instruments. This module has a sample rate of 750 kS/s for every channel, a Virtex-5 LX110 FPGA, 16 bits resolution, ±10 V input and output signal range, eight analog input channels, eight analog output channels, and 96 DIO channels. The three I/O connectors on this module are 68-pin female high-density VHDCI type. The NI PXI-7854R is 6.3 by 3.9 inches without connectors and weighs 152 grams. The small size and light weight ensure that this module can be carried anywhere the user requires it with ease.

The National Instruments PXI-7854R has a channel-to-earth maximum working voltage of ±12 V and channel-to-channel maximum working voltage of ±24 V, Measurement Category I. An important note to keep in mind is that the NI PXI-7854R cannot be used for linking to signals in Measurement Categories II, III, or IV. In addition, this RIO device meets the safety stipulations for electrical equipment for measurement, control, and laboratory use of the IEC 61010-1, EN 61010-1 and UL 61010-1, CSA 61010-1 standards.

The Virtex-5 LX110 FPGA permits the user to set the functionality and timing of the PXI-7854R module. The functionality of the FPGA can be modified in LabVIEW by utilizing the LabVIEW FPGA Module to generate and download a custom virtual instrument (VI) to the FPGA. With the FPGA module, the user can graphically design the timing and functionality of the PXI-7854R Multifunction Reconfigurable I/O Module.

PXI-7854R Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7854R (780342-01)
ManufacturerNational Instruments
SeriesR Series
TypePXI Multifunction Reconfigurable I/O Module
FPGAVirtex-5 LX110
Maximum Sample Rate750 kS/s
Channels8 AI, 8 AO, 96 digital
WarrantyOne Year Warranty
PXI-7854R ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.
